System And Components
7N9246 FAN BELT TIGHTENER GROUPSERIAL NO. 85X1 TO 85X505 INCLUSIVE
Group No: 7N9246
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5M5830 | 1 SCREW | 1 | |
| 7N5959 | 2 SPRING | 1 | |
| 2S6689 | 3 RETAINER | 1 | |
| 1D5117 | 4 NUT | 1 | |
| 2M2742 | 5 PLATE | 1 | |
| 0L1351 | 6 BOLT | 2 | |
| 5M2894 | 7 WASHER | 2 | |
| 1S8687 | 8 SPACER | 1 | |
| 8B2327 | 9 RETAINER | 1 | |
| 6B1124 | 10 BEARING | 2 | |
| 2S6150 | 11 COVER | 1 | |
| 2S6151 | GASKET | 1 | |
| 2S6160 | 12 WASHER | 1 | |
| 0S1618 | 13 BOLT | 4 | |
| 4N2697 | 14 PULLEY | 1 | |
| 5M9735 | 15 SEAL | 1 | |
| 4S7916 | 16 SPACER | 1 | |
| 2B2938 | 17 PIN | 1 | |
| 3B4617 | COTTER PIN | 1 | |
| 4N2693 | 18 ARM ASSEM. | 1 | |
| 4S5367 | BUSHING ASSEM. | 1 | |
| 4N0955 | DOWEL | 1 | |
| 0S1591 | 19 BOLT | 4 | |
| 4N2690 | 20 SHAFT ASSEM. | 1 | |
| 1S9209 | SHAFT | 1 | |
| 4N0955 | 21 DOWEL | 1 |
