System And Components
4N2293 ENGINE OIL LINES GROUP
Group No: 4N2293
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0S1594 | 1 BOLT (3/8-16X1.0IN) | 12 | |
| 9M7002 | 2 SEAL-O-RING | 2 | |
| 4N0933 | 3 GASKET | 1 | |
| 1W6135 | 4 TUBE AS-OIL FILTER INLET | 1 | |
| 1W6137 | 5 TUBE AS | 1 | |
| 1P1367 | 6 PLUNGER | 1 | |
| 4N8150 | 7 SPRING | 1 | |
| 2P3761 | 8 COVER | 1 | |
| 2P3760 | GASKET | 1 | |
| 4N1215 | 9 BODY-COOLER BYPASS | 1 | |
| 0S1588 | 10 BOLT (3/8-16X1.25IN) | 2 | |
| 6L1651 | 11 SEAL | 2 | |
| 2K4973 | 12 LOCKNUT (3/8-16 THD) | 2 | |
| 5P8068 | 13 SEAL-O-RING | 1 | |
| 5P5846 | 14 SEAL-O-RING | 1 | |
| 9X6458 | 15 WASHER-HARD (3MM THK) | 1 | |
| 1152370 | 16 TUBE AS-SUCTION | 1 | |
| 8T6765 | 17 PLUG-PIPE | 1 | |
| 0L1351 | 18 BOLT (3/8-16X0.875IN) | 3 | |
| 5M2894 | 19 WASHER (2.5MM THK) | 6 | |
| 1152353 | 20 BRACKET-TUBE | 1 | |
| 4N0995 | 21 TUBE AS | 1 | |
| 0S1591 | 22 BOLT (3/8-16X1.5IN) | 2 | |
| 4N1216 | 23 TUBE-COOLER BYPASS | 1 | |
| 9H6067 | SEAL-O-RING | 2 | |
| 4N0826 | 24 ELBOW-COOLER INLET | 1 | |
| 2S2251 | 25 SEAL-O-RING | 2 |
