System And Components
8N6402 FAN DRIVE GROUP-.800 DRIVE RATIOFOR USE WITH MOBILE EQUIPMENT
Group No: 8N6402
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9L0553 | 1 STUD-TAPERLOCK | 4 | |
| 1D4719 | NUT | 4 | |
| 1F7960 | WASHER | 4 | |
| 6N2547 | 2 ADAPTER-FAN BRACKET | 1 | |
| 5S9062 | 3 SPACER | 1 | |
| 5S2106 | 4 SEAL-LIP TYPE | 1 | |
| 0L2070 | 5 BOLT | 6 | |
| 7N8828 | 6 PULLEY-FAN | 1 | |
| 7N8827 | 7 HUB | 1 | |
| 3L1425 | 8 BALL BEARING | 1 | |
| 5S7264 | 9 WASHER-RETAINING 5.57MM(.219IN.)THK | 1 | |
| 7N2900 | WASHER-RETAINING 12.70MM(.500IN.)THK | 1 | |
| 6N6598 | 10 ADAPTER-FAN | 1 | |
| 1B5174 | 11 PLUG-PIPE | 1 | |
| 1H5403 | 12 BOLT 50.80MM(2IN.)LG | 2 | |
| 5P7979 | BOLT-SELF LOCKING 57.15MM(2.25IN.)LG | 2 | |
| 9F4446 | 13 SEAL-O-RING | 1 | |
| 2P2243 | 14 SPACER | 1 | |
| 8H9789 | 15 BALL BEARING | 1 | |
| 6N6490 | 16 BRACKET AS-FAN | 1 | |
| 2D4867 | 17 FITTING-HYDRAULIC | 1 | |
| 9L5595 | 18 BOLT | 1 | |
| 1D4717 | NUT | 1 | |
| 0S1594 | 19 BOLT | 2 | |
| 6N2538 | 20 BRACKET-FAN ADJUSTMENT | 1 | |
| 4B4550 | 21 FITTING-RELIEF | 1 |
