System And Components
7N7555 TURBOCHARGER GROUPREPLACED BY 9N888 SHOWN ON PAGE 214
Group No: 7N7555
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4N7601 | 1 CARTRIDGE GP | 1 | |
| 4N8124 | HOUSING AS-BEARING | 1 | |
| 5S5199 | PIN-GROOVE | 2 | |
| 4N7596 | 2 BACKPLATE-TURBINE | 1 | |
| 7N2856 | 3 RING-SEAL | 1 | |
| 4N7594 | 4 WHEEL AS | 1 | |
| 4M6983 | 5 RING-RETAINING | 4 | |
| 5S4557 | 6 BEARING | 2 | |
| 5S4547 | 7 SLEEVE-SPACER | 1 | |
| 4N7598 | 8 SLEEVE-FLINGER | 1 | |
| 4M8013 | 9 RING-PISTON | 1 | |
| 7N0239 | 10 NUT-TURBO COMPRESSOR | 1 | |
| 7N7723 | 11 WHEEL-COMPRESSOR | 1 | |
| 5S4556 | 12 INSERT | 1 | |
| 5S4549 | 13 DEFLECTOR-OIL | 1 | |
| 5S4546 | 14 RING-RETAINING | 1 | |
| 5P5727 | 15 SEAL | 1 | |
| 4N7597 | 16 BEARING AS | 1 | |
| 4N7609 | 17 RING-THRUST | 2 | |
| 2S1507 | 18 NAMEPLATE | 1 | |
| 8H3710 | SCREW-TAPPING | 1 | |
| 5S4517 | 19 CLAMP AS | 1 | |
| 7M9918 | NUT-SELF LOCKING | 1 | |
| 9N0048 | 20 HOUSING-TURBINE | 1 | |
| 4N8123 | 21 COVER-COMPRESSOR | 1 | |
| 7M9916 | 22 CLAMP AS | 1 | |
| 7M9918 | NUT-SELF LOCKING | 1 | |
| 6N7248 | KIT-CARTRIDGE | 1 |
