System And Components
3N8613 CLUTCH GROUP-PART 1TWIN DISC SPECIFICATION NO. 35544. PART OF 3N8617 REAR CLUTCH POWER
Group No: 3N8613
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5L3496 | 1 SLEEVE | 1 | |
| 5L3488 | 2 RING | 1 | |
| 5L3494 | 3 RING | 1 | |
| 5B2410 | 4 HOSE ASSEM. 15.50 in. (393 mm) | 1 | |
| 4H0008 | HOSE ASSEM. | 1 | |
| 3B8489 | 5 FITTING | 1 | |
| 9S1354 | NUT | 1 | |
| 6F0253 | LOCKWASHER | 1 | |
| 1L6931 | 6 SCREW ASSEM. | 2 | |
| 1N5392 | 7 PLATE (instruction) | 1 | |
| 5L3617 | 8 SEAL | 1 | |
| 4B0350 | 9 OIL CUP | 1 | |
| 3N8425 | 10 GAUGE | 1 | |
| 2F7771 | 11 KEY | 1 | |
| 3N9180 | 12 SHAFT | 1 | |
| 3N8428 | 13 SLINGER | 1 | |
| 0S1625 | 14 BOLT | 8 | |
| 5L3487 | 15 COLLAR ASSEM. | 1 | |
| 1B8702 | KEY | 1 | |
| 3N9179 | 16 HOUSING | 1 | |
| 8B7121 | FITTING | 2 |
