System And Components
1W8856 CLUTCH GROUP-PART 1PART OF 1W8857 REAR CLUTCH POWER TAKE-OFF GROUP SHOWN ON PAGE 425
Group No: 1W8856
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1L7796 | 1 KEY | 1 | |
| 1L5015 | 2 PLATE-CLUTCH | 1 | |
| 4L3527 | 3 PLATE-CLUTCH DRIVING | 3 | |
| 3N8125 | 4 PLATE AS-PRESSURE | 1 | |
| 3N8124 | SPRING-LOCK PIN | 1 | |
| 3N8123 | PIN-LOCK | 1 | |
| 3F3728 | 5 RING-SNAP | 1 | |
| 1L4863 | 6 WASHER-SPRING | 8 | |
| 6L3972 | 7 PIN | 4 | |
| 4H0002 | 8 LEVER | 4 | |
| 6L3961 | 9 COTTER | 4 | |
| 4B4721 | 10 LINK | 8 | |
| 6L3967 | 11 PIN | 8 | |
| 6L3964 | 12 COTTER | 8 | |
| 5B2410 | 13 HOSE AS | 1 | |
| 4B4716 | 14 COLLAR AS-SLEEVE | 1 | |
| 0L0639 | BOLT | 2 | |
| 2L6267 | LOCKNUT | 2 | |
| 4B4758 | SHIM | 2 | |
| 6B3223 | 15 CUP-BEARING | 2 | |
| 4B7270 | 16 CONE-BEARING | 2 | |
| 4B4764 | 17 NUT | 1 | |
| 4B4773 | 18 LOCK | 1 | |
| 5L3486 | 19 RING-DRIVING | 1 | |
| 3H9571 | 20 PLATE-CENTER | 2 | |
| 3H9572 | 21 RING-ADJUSTING | 1 | |
| 3H9574 | 22 SLEEVE (SLIDING) | 1 | |
| 4B4792 | 23 YOKE AS | 1 | |
| 0S1591 | BOLT | 2 | |
| 3B4506 | LOCKWASHER | 2 | |
| 6L5151 | 24 KEY-WOODRUFF | 2 | |
| 3L0648 | 25 SHAFT-OPERATING | 1 | |
| 5B2404 | 26 RETAINER-BEARING | 1 | |
| 5B2407 | 27 LOCK | 1 | |
| 0S1617 | 28 BOLT | 1 | |
| 3F9556 | LOCKWASHER | 1 |
