System And Components
2W4902 CLUTCH GROUPPART OF 2W4903 REAR POWER TAKE-OFF GROUP SHOWN ON PAGE 425A
Group No: 2W4902
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4L3527 | 1 PLATE-CLUTCH DRIVING | 2 | |
| 5L9652 | 2 HUB | 1 | |
| 8B7987 | 3 KEY | 1 | |
| 5L9653 | 4 NUT | 1 | |
| 5L9654 | LOCK | 1 | |
| 3H9571 | 5 PLATE-CENTER | 1 | |
| 5N9317 | 6 RING-DRIVING | 1 | |
| 7F8897 | 7 PLATE-HANDHOLE | 1 | |
| 3H9572 | 8 RING-ADJUSTING | 1 | |
| 3H9574 | 9 SLEEVE | 1 | |
| 4B4754 | 10 SHAFT | 1 | |
| 6L5151 | KEY-WOODRUFF | 2 | |
| 4B4792 | 11 YOKE AS | 1 | |
| 0S1591 | 12 BOLT | 2 | |
| 3B4506 | LOCKWASHER | 2 | |
| 1A1460 | 13 BOLT | 6 | |
| 3B4508 | LOCKWASHER | 6 | |
| 5L9655 | 14 RETAINER-BEARING | 1 | |
| 9S1354 | 15 NUT | 1 | |
| 6F0253 | LOCKWASHER | 1 | |
| 0S1617 | 16 BOLT | 1 | |
| 3F9556 | LOCKWASHER | 1 | |
| 5B2407 | LOCK | 1 | |
| 4B4716 | 17 COLLAR AS-SLEEVE | 1 | |
| 0L0639 | 18 BOLT | 2 | |
| 2L6267 | LOCKNUT | 2 | |
| 4B4758 | SHIM | 2 | |
| 5B2410 | 19 HOSE AS 38.1CM(15IN) | 1 | |
| 4B4721 | 20 LINK | 8 | |
| 6L3967 | PIN | 8 | |
| 6L3964 | COTTER | 8 | |
| 6L3972 | 21 PIN | 4 | |
| 6L3961 | COTTER | 4 | |
| 1L4863 | WASHER-SPRING | 8 | |
| 4H0002 | 22 LEVER | 4 | |
| 2W7883 | 23 PLATE-INSTRUCTION | 1 | |
| 3N8125 | 24 PLATE AS-PRESSURE | 1 | |
| 3N8124 | 25 SPRING-LOCK PIN | 1 | |
| 3N8123 | PIN-LOCK | 1 | |
| 8B7121 | 26 FITTING-HYDRAULIC | 2 | |
| 3N4896 | 27 SHAFT-CLUTCH | 1 | |
| 1L6931 | 28 SCREW AS-MACHINE | 4 | |
| 6B3223 | 29 CUP-BEARING | 2 | |
| 4B7270 | 30 CONE-BEARING | 2 | |
| 4B4810 | 31 LEVER AS-HAND | 1 | |
| 7F8916 | 32 CARRIER-BEARING | 1 | |
| 3B8489 | 33 FITTING-GREASE | 2 | |
| 7W7155 | 34 HOUSING-CLUTCH | 1 | |
| 3N4128 | CLUTCH AS | 1 |
