System And Components
3N4128 CLUTCH ASSEMBLYPROVIDES FIELD REPLACEMENT FOR 2W4902 CLUTCH GROUP SHOWN ON PAGE 434A
Group No: 3N4128
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5L9652 | 1 HUB | 1 | |
| 4L3527 | 2 PLATE-CLUTCH DRIVING | 2 | |
| 3H9571 | 3 PLATE-CENTER | 1 | |
| 3N8125 | 4 PLATE AS-PRESSURE | 1 | |
| 3N8123 | 5 PIN-LOCK | 1 | |
| 3N8124 | 6 SPRING-LOCK PIN | 1 | |
| 4H0002 | 7 LEVER | 4 | |
| 4B4721 | 8 LINK | 8 | |
| 3H9574 | 9 SLEEVE | 1 | |
| 4B4716 | 10 COLLAR AS-SLEEVE | 1 | |
| 0L0639 | 11 BOLT | 2 | |
| 2L6267 | LOCKNUT | 2 | |
| 4B4758 | 12 SHIM | 2 | |
| 3H9572 | 13 RING-ADJUSTING | 1 | |
| 6L3967 | 14 PIN | 8 | |
| 6L3964 | COTTER | 8 | |
| 6L3972 | 15 PIN | 8 | |
| 6L3961 | COTTER | 8 | |
| 1L4863 | WASHER-SPRING | 8 | |
| 8B7987 | 16 KEY | 1 |
