System And Components
7N2850 AIR COMPRESSOR GROUP6N3611 AIR COMPRESSOR PARTS ARE SHOWN ON PAGE 442
Group No: 7N2850
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3B4618 | 1 COTTER | 1 | |
| 6N8643 | 2 PULLEY-AIR COMPRESSOR | 1 | |
| 6N3611 | 3 AIR COMPRESSOR GP | 1 | |
| 6N3135 | 4 SUMP-COMPRESSOR | 1 | |
| 6B7254 | 5 STUD | 3 | |
| 0L0765 | 6 STUD | 2 | |
| 6N3399 | 7 BRACKET AS | 1 | |
| 0S1594 | 8 BOLT | 6 | |
| 5M2894 | 9 WASHER | 9 | |
| 9L4238 | 10 BOLT | 1 | |
| 6N0634 | 11 GASKET-COVER | 1 | |
| 1D4703 | 12 BOLT | 4 | |
| 1D4718 | NUT-FULL | 4 | |
| 4S9191 | WASHER | 8 | |
| 6N7721 | 13 V-BELT | 1 | |
| 1D4717 | 14 NUT | 3 | |
| 5B4274 | 15 BOLT | 1 | |
| 1B7182 | 16 BOLT | 3 | |
| 9M1974 | WASHER | 3 | |
| 3B1915 | 17 BOLT | 1 | |
| 0S1608 | 18 BOLT | 2 | |
| 6N7705 | 19 ADAPTER | 1 | |
| 1S1225 | SEAL-O-RING | 1 |
