System And Components
6N3611 AIR COMPRESSOR GROUPPART OF 7N2850 AIR COMPRESSOR GROUP SHOWN ON PAGE 440
Group No: 6N3611
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5M6214 | 1 PLUG-PIPE | 2 | |
| 6N2100 | 2 COVER AS-REAR | 1 | |
| 6N2099 | 3 CRANKCASE AS | 1 | |
| 6N2097 | 4 HEAD AS-COMPRESSOR | 1 | |
| 3J5390 | PLUG | 1 | |
| 3J5389 | 5 PLUG | 2 | |
| 6N2098 | 6 GASKET-HEAD | 1 | |
| 9M0397 | 7 ADAPTER-INLET | 1 | |
| 8M7065 | GASKET-AIR INLET | 2 | |
| 2B2695 | 8 BOLT | 2 | |
| 3B4505 | LOCKWASHER | 2 | |
| 7N4837 | 9 PISTON AS-COMPRESSOR | 2 | |
| 3F5289 | 10 KEY-CRANKSHAFT | 1 | |
| 7F6547 | 11 NUT | 1 | |
| 6N5878 | 12 CRANKSHAFT | 1 | |
| 6N2106 | 13 ROD AS-CONNECTION | 2 | |
| 6N5877 | 14 COVER-FRONT | 1 | |
| 6N5876 | GASKET-FRONT COVER | 1 | |
| 5P0060 | 15 BOLT | 4 | |
| 3B4507 | 16 LOCKWASHER | 8 | |
| 0S1619 | 17 BOLT | 6 | |
| 3L0526 | 18 BOLT | 4 | |
| 5M6509 | 19 SEAL-O-RING | 1 | |
| 8N3665 | 20 KIT-O-RING SEAL | 2 | |
| 8H9789 | 21 BALL BEARING | 1 | |
| 2H5021 | 22 SEAL-LIP TYPE | 1 | |
| 8N3666 | KIT-AIR COMPRESSOR (COMPRESSOR) | 1 | |
| 6N2109 | KIT-PISTON RINGS | 1 |
