Assembly
100%

1376336 AFTERCOOLER GP-WATER

Group No: 1376336
Part NumberPart NameQty
1B95751 BOLT (5/16 X 18 X 1.75IN)11
9M19742 WASHER-HARD (2MM THK)26
8N80993 COVER-AFTERCOOLER1
8T67654 PLUG-PIPE1
8T67645 PLUG-PIPE (1/8 X 27 THD)1
5M28946 WASHER (2.5MM THK)12
1W05127 COVER-AFTERCOOLER1
7W06888 GASKET-ADAPTER2
7W64929 PLUG-PIPE (1/2 X 14 THD)1
031021910 BOLT-LOCKING1
5M2894WASHER (2.5MM THK)1
4N900811 GASKET2
6L958912 GASKET2
5D984413 BOLT-LOCKING1
4W477514 ADAPTER2
4N419315 ADAPTER2
109007816 SEAL-O-RING (33.47MM ID)2
5P720417 SEAL-O-RING2
1W487918 CORE AS-AFTERCOOLER1
8N809819 HOUSING-AFTERCOOLER1
8T676420 PLUG-PIPE3
2N820421 GASKET6
3E743022 PLUG-PIPE1
031021923 BOLT-LOCKING10
5B562024 BOLT (5/16-18X2.125IN)22
8T676225 PLUG-PIPE1
1B957526 BOLT (5/16 X 18 X 1.75IN )1
5B5620BOLT (5/16 X 18 X 2.125IN)1
