9N1105 CYLINDER HEAD GP*RENGINE S/N 79V8432-8714

Group No: 9N1105
Part NumberPart NameQty
7H31711 PLUG-PIPE1
5M62132 PLUG-PIPE3
0L13293 BOLT (1/2-13X3 IN)(LOCATION E)8
3H76544 WASHER-HARD (13.5X22.5X3MM THK)36
5B96035 BOLT (3/8-16X5 IN)(LOCATION D)6
6F52826 BOLT (1/2-13X5.25 IN)(LOCATION A)8
2B20067 BOLT (1/2-13X4.75 IN)(LOCATION F)12
2B09478 BOLT (1/2-13X2.25 IN)(LOCATION G)8
9N31119 CYLINDER HEAD AS2
9L7657PLUG-CUP1
9N283710 INSERT-SEAT (EXHAUST)4
0L132911 BOLT (1/2-13X3 IN)(LOCATION H)3
8M586012 PLUG-CUP4
5M621413 PLUG-PIPE1
5M621314 PLUG-PIPE1
0S157115 BOLT (3/8-16X1.75 IN)(LOCATION C-LEFT HEAD)1
9L9166STUDBOLT (3/8-16X3.63 IN)(LEFT HEAD)1
9L888916 WASHER16
9N338717 SPRING-VALVE OUTER16
9L942518 RETAINER-SPRING16
2A442919 LOCK-RETAINER32
9L916420 GASKET-CYLINDER HEAD2
9L768321 VALVE-EXHAUST8
9L768222 VALVE-INLET8
2N8943INSERT-VALVE SEAT (INLET)8
9N090623 SPACER16
