System And Components
7N-8876 CYLINDER HEAD GPS/N 08Z64021-UP
Group No: 7N-8876
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7S7144 | 1 SPRING-VALVE | 12 | |
| 1W5300 | 2 ROTOCOIL AS | 12 | |
| 6N7174 | SHIELD-OIL | 1 | |
| 2A4429 | 3 LOCK-RETAINER | 24 | |
| 3S5496 | 4 SEAL-O-RING | 1 | |
| 1118015 | 5 GASKET AS-CYLINDER HEAD | 1 | |
| 1007860 | 6 VALVE-INLET | 6 | |
| 1487455 | 7 VALVE-EXHAUST | 6 | |
| 9Y1798 | 8 SEAL | 18 | |
| 1487425 | 9 GUIDE-VALVE (STANDARD) | 12 | |
| 1546997 | GUIDE-VALVE (0.51-MM OS) | ||
| 1546998 | GUIDE-VALVE (0.13-MM OS) | ||
| 7C4006 | 10 CYLINDER HEAD AS | 1 | |
| 3S8313 | 10A PLUG-CUP | 7 | |
| 3P1896 | 10B PLUG-CUP (35.31-MM OD) | 13 | |
| 3B0623 | 10C PLUG-CUP (25.73-MM OD) | 6 | |
| 1070268 | 11 INSERT-VALVE SEAT (INLET)(STANDARD) | 6 | |
| 1118021 | INSERT-VALVE SEAT (0.13-MM OS, INLET) | ||
| 1118022 | INSERT-VALVE SEAT (0.25-MM OS, INLET) | ||
| 1118023 | INSERT-VALVE SEAT (0.51-MM OS, INLET) | ||
| 1118024 | INSERT-VALVE SEAT (0.76-MM OS, INLET) | ||
| 1070265 | 12 INSERT-VALVE SEAT (EXHAUST)(STANDARD) | 6 | |
| 1118025 | INSERT-VALVE SEAT (0.13-MM OS, EXHAUST) | ||
| 1118026 | INSERT-VALVE SEAT (0.25-MM OS, EXHAUST) | ||
| 1118027 | INSERT-VALVE SEAT (0.51-MM OS, EXHAUST) | ||
| 1118028 | INSERT-VALVE SEAT (0.76-MM OS, EXHAUST) | ||
| 8T6762 | 13 PLUG-PIPE (1/2-14-THD) | 3 | |
| 7N8018 | 14 SEAL | 6 | |
| 8T6763 | 15 PLUG-PIPE (1/4-18-THD) | 1 |
