System And Components
8V-1353 DIFFERENTIAL & BEVEL GEAR GPS/N 17Z1-492; 17Z494-615
Group No: 8V-1353
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4V5401 | 1 DIFFERENTIAL GP | 1 | |
| 0300060 | 2 CUP-BEARING (TAPERED ROLLER) | 1 | |
| 0300061 | CONE-BEARING (TAPERED ROLLER) | 1 | |
| 8D2653 | 3 NUT | 1 | |
| 5M7329 | 4 SEAL-O-RING | 1 | |
| 4V5387 | 5 CARRIER AS-DIFFERENTIAL | 1 | |
| 3B2968 | 6 BOLT (3/4-10X3.5-IN) | 2 | |
| 0S1756 | BOLT (3/4-10X4.25-IN) | 2 | |
| 5P8248 | WASHER-HARD (20X36.5X3.5-MM THK) | 4 | |
| 3J0634 | 7 SEAL-O-RING | 1 | |
| 1A1135 | 8 BOLT (5/8-11X2-IN) | 12 | |
| 5P8247 | 9 WASHER-HARD (17X32X3.5-MM THK) | 36 | |
| 2V7344 | 10 HOUSING-BEARING SUPPORT | 1 | |
| 0343557 | 11 BOLT-LOCKING (3/8-16X1.125-IN) | 6 | |
| 5M2894 | WASHER-HARD (10.2X18.5X2.5-MM THK) | 6 | |
| 5P5813 | 12 LOCKNUT-BEARING (2.75X18-THD) | 2 | |
| 4V6104 | 13 RETAINER-OIL SEAL | 1 | |
| 2K5109 | GASKET | 1 | |
| 4V5388 | 14 SHAFT-BEVEL PINION | 1 | |
| 5K4040 | PLUG | 1 | |
| 5K2595 | 15 SEAL-LIP TYPE | 1 | |
| 4V7173 | 16 LOCKNUT | 1 | |
| 5L2031 | 17 CUP-BEARING (TAPERED ROLLER) | 1 | |
| 5L2030 | CONE-BEARING | 1 | |
| 1J2860 | 18 CUP-BEARING (TAPERED ROLLER) | 1 | |
| 1J4757 | CONE-BEARING (TAPERED ROLLER) | 1 | |
| 4V5395 | 19 SHIM PACK (INCLUDES 20-SHIMS) | 1 | |
| 2A1538 | 20 BOLT (3/4-10X2.25-IN) | 12 | |
| 8V1715 | SPACER (20.5X35X12-MM THK) | 12 | |
| 8D2628 | 21 NUT (5-13/16-12-THD) | 1 | |
| 1P3934 | 22 CUP-BEARING | 1 | |
| 1P3935 | CONE-BEARING | 1 | |
| 2K0537 | 23 LOCK-BEARING | 2 | |
| 0S0214 | 24 BOLT | 2 | |
| 5P6628 | 25 LOCKWIRE | ||
| 1K6694 | 26 BOLT | 24 | |
| 4V5393 | 27 GEAR-BEVEL (39-TEETH) | 1 |
