System And Components
5V-0718 WHEEL GP-FINAL DRIVE & BRAKES/N 17Z840-UP
Group No: 5V-0718
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9G5315 | 1 SEAL GP-DUO-CONE | 1 | |
| 2M0344 | RING-SEALING | 2 | |
| 0310219 | 2 BOLT-LOCKING (3/8-16X1.75-IN) | 4 | |
| 4K7342 | 3 BAR | 4 | |
| 4V7334 | 4 BRAKE GP-SERVICE | 1 | |
| 4F2041 | 5 CUP-BEARING (TAPERED ROLLER) | 1 | |
| 6V1882 | 6 CONE-BEARING | 1 | |
| 2K5069 | 7 CUP-BEARING (TAPERED ROLLER) | 1 | |
| 6V0855 | 8 BEARING AS-TAPERED ROLLER | 1 | |
| 1035961 | 9 WHEEL | 1 | |
| 9C5852 | 10 HUB AS | 1 | |
| 2V5715 | BUSHING-TERMINAL | 1 | |
| 2V5656 | 11 RING-SNAP | 1 | |
| 2V7390 | 12 SHIM PACK (INCLUDES 15-SHIMS) | 1 | |
| 2V5722 | 13 CARRIER | 1 | |
| 8D2714 | 14 SEAL-O-RING | 1 | |
| 0S1585 | 15 BOLT (1/2-13X1.5-IN) | 6 | |
| 5P8245 | 16 WASHER-HARD (13.5X25.5X3-MM THK) | 6 | |
| 2V7092 | 17 PLATE-RETAINER | 1 | |
| 7K6058 | 18 BOLT-12 POINT HEAD (1/2-13X2.5-IN) | 8 | |
| 9U3125 | 19 GEAR-SUN (16-TEETH) | 1 | |
| 2V5697 | 20 COVER AS | 1 | |
| 2D0604 | BUTTON | 1 | |
| 9C3838 | 21 WASHER-THRUST | 6 | |
| 1864439 | 22 GEAR-PLANETARY (23-TEETH) | 3 | |
| 1864440 | 23 SHAFT-PLANETARY | 3 | |
| 2V7398 | 24 RING-RETAINING | 3 | |
| 2R0239 | 25 SEAL-O-RING | 1 | |
| 5P4484 | 26 PLUG-MAGNETIC | 1 | |
| 7M8485 | 27 SEAL-O-RING | 1 | |
| 1A1135 | 28 BOLT (5/8-11X2-IN) | 20 | |
| 5P8247 | 29 WASHER-HARD (17X32X3.5-MM THK) | 20 | |
| 2V5714 | 30 GEAR-RING (65-TEETH) | 1 | |
| 9C4007 | 31 BUSHING | 3 | |
| 5V1708 | 32 STUD (3/4-16X3.15-IN) | 20 | |
| 4K6810 | 33 RETAINER-SEAL | 1 | |
| 4K6804 | 34 SEAL-O-RING | 1 | |
| 4V5213 | 35 SPINDLE | 1 | |
| 5H3252 | 36 SEAL-O-RING | 1 |
