System And Components
4V-7171 BRAKE GP-PARKINGS/N 17Z977-1040
Group No: 4V-7171
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8R2493 | 1 ACTUATOR GP-BRAKE | 1 | |
| 6V8181 | 2 NUT-FULL (5/8-18-THD) | 2 | |
| 5P8247 | 3 WASHER-HARD (17X32X3.5-MM THK) | 4 | |
| 9S1354 | 4 NUT (5/8-18-THD) | 1 | |
| 9D8632 | 5 END-YOKE ROD | 1 | |
| 4K1540 | 6 PIN-CLEVIS | 1 | |
| 3B4617 | PIN-COTTER | 1 | |
| 7V1881 | 7 LEVER | 1 | |
| 4V3360 | 8 GUARD AS | 1 | |
| 9B7237 | 9 BOLT (3/8-16X1.25-IN) | 1 | |
| 0S1587 | 10 BOLT (1/2-13X1.75-IN) | 8 | |
| 5M3062 | 11 BOLT (3/8-16X0.75-IN) | 4 | |
| 8T4896 | WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 5P8245 | 12 WASHER-HARD (13.5X25.5X3-MM THK) | 11 | |
| 4V3253 | 13 WASHER | 1 | |
| 6W7282 | 14 BRAKE GP-PARKING | 1 | |
| 4V6040 | 15 DRUM | 1 | |
| 0S1589 | 16 BOLT (5/8-11X1.75-IN) | 4 | |
| 6H1717 | 17 BOLT (1/2-13X1.125-IN) | 3 | |
| 7V1939 | 18 BRACKET AS | 1 | |
| 8T4122 | 19 WASHER-HARD (17X32X3.5-MM THK) | 2 | |
| 1K6776 | 20 PLUG-PROTECTION | 2 | |
| 9V8698 | KIT-BOOT (AIR CHAMBER) | 1 |
