System And Components
1U-2230 VALVE GP-STEERINGS/N 17Z1-UP
Group No: 1U-2230
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3G0632 | 1 VALVE GP-STEERING | 1 | |
| 9S8001 | 2 PLUG (5/16-24-THD) | 2 | |
| 4J7533 | SEAL-O-RING | 2 | |
| 8J8451 | 3 COVER | 1 | |
| 4J5309 | 4 SEAL-O-RING | 6 | |
| 4J0523 | 5 SEAL-O-RING | 3 | |
| 0L1329 | 6 BOLT (1/2-13X3-IN) | 2 | |
| 9S1366 | BOLT (1/2-13X2.5-IN) | 2 | |
| 0S1587 | 7 BOLT (1/2-13X1.75-IN) | 2 | |
| 9S4187 | 8 PLUG | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 3H2549 | 9 SHIM (0.254-MM THK) | 14 | |
| 2J6089 | 10 SPRING | 1 | |
| 9J7795 | 11 VALVE GP-STEERING | 1 | |
| 4J0519 | 12 SEAL-O-RING | 1 | |
| 2J6088 | 13 SPRING (OUTER) | 1 | |
| 4J7490 | 14 SPRING (INNER) | 1 | |
| 8J8450 | 15 COVER | 1 | |
| 3J1907 | 16 SEAL-O-RING | 1 | |
| 9S6154 | 17 PLUG AS | 1 | |
| 1P4577 | 18 FLANGE-HALF | 4 | |
| 0S1588 | 19 BOLT (3/8-16X1.25-IN) | 8 | |
| 5M2894 | WASHER-HARD (10.2X18.5X2.5-MM THK) | 8 | |
| 8J8466 | 20 STOP | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 1U2556 | 21 PLATE-IDENTIFICATION | 1 | |
| 7B3028 | SCREW-DRIVE (NO 4X 3/16-IN) | 1 | |
| 9H2367 | 22 SPRING-VALVE | 1 | |
| 4B9782 | 23 BALL | 1 |
