System And Components
8N0817 CARTRIDGE GP-TURBOCHARGER*RENGINE S/N 70V22477-UP
Group No: 8N0817
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8N0819 | 1 BACKPLATE AS | 1 | |
| 1P1120 | 2 RING-SEAL | 1 | |
| 6N5004 | 3 BEARING-THRUST | 1 | |
| 7N3759 | 4 RING-PISTON | 1 | |
| 7N3760 | 5 SHROUD-TURBINE WHEEL | 1 | |
| 6N8632 | 6 SHAFT & WHEEL AS | 1 | |
| 9M8915 | 7 RING-RETAINING | 3 | |
| 9N2035 | 8 HOUSING AS-CENTER | 1 | |
| 4M6646 | PIN-GROOVE | 2 | |
| 9M8911 | 9 COLLAR-THRUST | 1 | |
| 9N2046 | 10 SPACER-THRUST | 1 | |
| 9M8919 | RING-SEAL | 2 | |
| 3S4484 | 11 LOCKNUT-TURBOCHARGER | 1 | |
| 8N0818 | 12 WHEEL-COMPRESSOR | 1 | |
| 0S1616 | 13 BOLT | 4 | |
| 9N2036 | PLATE-LOCK | 4 | |
| 9N2041 | 14 KIT-BEARING | 1 | |
| 7N3193 | KIT-BEARING | 1 | |
| 7N3194 | KIT-BEARING | 1 | |
| 9N2047 | NAMEPLATE-CARTRIDGE | 1 | |
| 2F0808 | SCREW | 2 | |
| 1W7212 | CARTRIDGE GP-TURBOCHARGER | 1 |
