System And Components
1N-3348 LINES GP-ENGINE OIL FILTERS/N 73W3403-9109
Group No: 1N-3348
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0T0772 | 1 BOLT (7/16-14X1.5-IN) | 16 | |
| 5P8244 | 2 WASHER-HARD (12X22.5X2.5-MM THK) | 16 | |
| 8N6148 | 3 HOSE AS | 1 | |
| 1P4578 | 4 FLANGE-HALF | 8 | |
| 8M4986 | 5 SEAL-O-RING | 4 | |
| 0308194 | 6 CONNECTOR | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 8N7806 | 7 HOSE AS | 1 | |
| 0321268 | 8 CONNECTOR (90-DEG) | 1 | |
| 8N6149 | 9 HOSE AS | 1 | |
| 4N8600 | 10 ADAPTER-BASE | 1 | |
| 2P4305 | 11 GASKET | 2 | |
| 1A2029 | 12 BOLT (3/8-16X1.125-IN) | 4 | |
| 5M2894 | 13 WASHER-HARD (10.2X18.5X2.5-MM THK) | 13 | |
| 0S1591 | 14 BOLT (3/8-16X1.5-IN) | 6 | |
| 6N7896 | 15 SUPPORT AS-OIL FILTER | 1 | |
| 2P8813 | 16 SUPPORT-BASE | 1 | |
| 0S1571 | 17 BOLT (3/8-16X1.75-IN) | 2 | |
| 1D4717 | 18 NUT (3/8-16-THD) | 4 | |
| 1A1460 | 19 BOLT (1/2-13X2-IN) | 4 | |
| 5P8245 | WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 9F6304 | 20 SPRING | 2 | |
| 9M0853 | 21 PLUNGER-VALVE | 2 | |
| 4N0861 | 22 COVER | 1 | |
| 4N0865 | GASKET | 1 | |
| 0S1608 | 23 BOLT (3/8-16X3.75-IN) | 1 | |
| 4N8770 | 24 ELBOW-COOLER OUTLET | 1 | |
| 0T0065 | BOLT (3/8-16X3.5-IN) | 1 | |
| 4N8411 | 25 TUBE-COOLER BYPASS | 1 | |
| 9M4849 | 26 SEAL-O-RING | 2 | |
| 1N2989 | 27 BRACKET-FILTER | 1 | |
| 0L2070 | 28 BOLT (3/8-16X2.25-IN) | 3 | |
| 6L1651 | 29 SEAL-O-RING | 3 | |
| 1W1116 | 30 BODY-BYPASS | 1 | |
| 0S1594 | 31 BOLT (3/8-16X1-IN) | 10 | |
| 9M7002 | 32 SEAL-O-RING | 1 |
