Assembly
100%

1N-3213 LINES GP-AIRS/N 49Z1-99999

Group No: 1N-3213
Part NumberPart NameQty
9M21511 STUD-TAPERLOCK (3/8-16X1.378-IN)20
2W01342 ADAPTER-AIR CLEANER (RH)1
7M1674SCREEN-AIR CLEANER INLET1
5P25663 BOLT (1/2-13X1.5-IN)8
8T4223WASHER-HARD (13.5X25.5X3-MM THK)8
2W01354 ADAPTER-AIR CLEANER (LH)1
7M1674SCREEN-AIR CLEANER INLET1
3B65525 ELBOW-PIPE2
1W06136 INDICATOR AS-AIR FILTER CHANGE (SERVICE)2
2M51737 SEAL-O-RING8
5M28948 WASHER-HARD (10.2X18.5X2.5-MM THK)12
2A46399 BOLT (3/8-16X1.625-IN)6
1B5355NUT-FULL (3/8-16-THD)6
5P256610 BOLT (1/2-13X1.5-IN)8
8T4223WASHER-HARD (13.5X25.5X3-MM THK)8
6B000211 GASKET2
6N161512 PIPE-AIR TRANSFER1
4N852213 ELBOW2
1N415914 PIPE-AIR TRANSFER1
5L885415 RING-SEALING4
4N115716 COUPLING-EXHAUST2
1N311317 SUPPORT-ELBOW2
3B728518 NIPPLE-PIPE2
