System And Components
7V-8427 LINES GP-POWER TRAIN OILS/N 49Z1-318
Group No: 7V-8427
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7V8631 | 1 HOSE AS | 1 | |
| 4J0522 | 2 SEAL-O-RING | 3 | |
| 1P4578 | 3 FLANGE-HALF | 6 | |
| 3H5368 | 4 BOLT (7/16-14X1.375-IN) | 8 | |
| 5P8244 | 5 WASHER-HARD (12X22.5X2.5-MM THK) | 12 | |
| 6D0837 | 6 ELBOW | 1 | |
| 1D4556 | 7 BOLT (7/16-14X2.75-IN) | 4 | |
| 1P4579 | 8 FLANGE-HALF | 6 | |
| 0S1585 | 9 BOLT (1/2-13X1.5-IN) | 20 | |
| 5P8245 | 10 WASHER-HARD (13.5X25.5X3-MM THK) | 20 | |
| 4J0524 | 11 SEAL-O-RING | 3 | |
| 1P4582 | 12 FLANGE-HALF | 2 | |
| 4J0527 | 13 SEAL-O-RING | 1 | |
| 7M3882 | 14 CLIP | 1 | |
| 2R6806 | 15 CONNECTOR | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 4V1121 | 16 HOSE AS | 1 | |
| 0S1588 | 17 BOLT (3/8-16X1.25-IN) | 2 | |
| 1D4717 | NUT (3/8-16-THD) | 2 | |
| 5P1075 | 18 WASHER-HARD (10.2X22.5X3-MM THK) | 4 | |
| 9G3548 | 19 SWITCH GP | 1 | |
| 4J0524 | 20 SEAL-O-RING | 2 | |
| 0307950 | 21 ELBOW | 1 | |
| 3D2824 | 22 SEAL-O-RING | 2 | |
| 3P6164 | 23 HOSE AS | 1 | |
| 1P4582 | 24 FLANGE-HALF | 4 | |
| 0S1585 | 25 BOLT (1/2-13X1.5-IN) | 12 | |
| 5P8245 | 26 WASHER-HARD (13.5X25.5X3-MM THK) | 12 | |
| 3H5368 | 27 BOLT (7/16-14X1.375-IN) | 4 | |
| 5P8244 | 28 WASHER-HARD (12X22.5X2.5-MM THK) | 4 | |
| 4J0522 | 29 SEAL-O-RING | 1 | |
| 1P4578 | 30 FLANGE-HALF | 2 | |
| 4V1119 | 31 HOSE AS | 1 | |
| 2R6276 | 32 CONNECTOR | 1 | |
| 2V0600 | 33 CLAMP-HALF | 2 | |
| 5P1076 | 34 WASHER-HARD (13.5X30X4-MM THK) | 10 | |
| 4V0884 | 35 ADAPTER | 1 | |
| 1P3707 | 36 SEAL-RECTANGULAR | 1 | |
| 0V0375 | 37 BOLT (1/2-13X3.25-IN) | 4 | |
| 8S9089 | 38 BOLT (1/2-13X4.5-IN) | 4 | |
| 1D4719 | 39 NUT-FULL (1/2-13-THD) | 4 | |
| 4V1125 | 40 BRACKET | 2 | |
| 4V1123 | 41 CLAMP-HALF | 4 | |
| 0S1621 | BOLT (1/2-13X1-IN) | 4 | |
| 3V5879 | 42 HOSE AS (238CM 93.7IN) | 1 | |
| 1P4579 | 43 FLANGE-HALF | 4 | |
| 4J0527 | 44 SEAL-O-RING | 3 | |
| 4F5192 | 45 BOLT (7/16-14X3-IN) | 2 | |
| 1D4707 | 46 BOLT (7/16-14X2.25-IN) | 2 | |
| 8P2843 | 47 PUMP GP-TRANSMISSION | 1 | |
| 7V0557 | 48 TUBE AS | 1 | |
| 2R6806 | 49 CONNECTOR | 5 | |
| 3J1907 | 50 SEAL-O-RING | 5 | |
| 3V5877 | 51 HOSE AS | 1 | |
| 4S5414 | 52 SLEEVE | 2 | |
| 8S6417 | COUPLING AS | 2 | |
| 6P6569 | 53 VALVE GP-SEQUENCE & PRESS CONT | 1 | |
| 8M4447 | SEAL-O-RING | 1 | |
| 0L1143 | 54 BOLT (3/8-16X2.5-IN) | 3 | |
| 8M4988 | SEAL-O-RING | 3 | |
| 3V5878 | 55 HOSE AS | 1 | |
| 8S6417 | 56 COUPLING AS | 1 | |
| 4S5414 | 57 SLEEVE | 2 | |
| 8S6393 | 58 COUPLING AS | 1 | |
| 0619258 | 59 TEE | 1 | |
| 6K9194 | 60 ELBOW | 1 | |
| 3V5906 | 61 TUBE AS | 1 | |
| 0530700 | 62 TEE-SWIVEL (FLARED) | 1 | |
| 0307962 | 63 ELBOW | 1 | |
| 3V5882 | 64 HOSE AS | 1 | |
| 4J0522 | 65 SEAL-O-RING | 1 | |
| 3H5368 | 66 BOLT (7/16-14X1.375-IN) | 4 | |
| 5P8244 | 67 WASHER-HARD (12X22.5X2.5-MM THK) | 4 | |
| 1P4578 | 68 FLANGE-HALF | 2 | |
| 0T0065 | 69 BOLT (3/8-16X3.5-IN) | 3 | |
| 8M8157 | 70 SEAL-O-RING | 1 | |
| 1P4579 | 71 FLANGE-HALF | 4 | |
| 4V1120 | 72 HOSE AS | 1 | |
| 4J0524 | 73 SEAL-O-RING | 2 | |
| 0S1585 | 74 BOLT (1/2-13X1.5-IN) | 8 | |
| 5P8245 | 75 WASHER-HARD (13.5X25.5X3-MM THK) | 8 | |
| 8P1471 | 76 VALVE GP-RELIEF (CONVERTER OUTLET) | 1 | |
| 8M4443 | SEAL-O-RING | 1 | |
| 3H5841 | 77 BOLT (3/8-16X1-IN) | 3 | |
| 5M2894 | 78 WASHER-HARD (10.2X18.5X2.5-MM THK) | 7 | |
| 8V3557 | 79 BRACKET AS | 1 | |
| 0L1351 | 80 BOLT (3/8-16X0.875-IN) | 4 | |
| 9P0856 | 81 FILTER GP-OIL (POWER TRAIN) | 1 | |
| 7V8532 | 82 SPACER | 1 | |
| 9G3341 | 83 SWITCH AS-TEMPERATURE | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 7V8630 | 84 HOSE AS | 1 |
