System And Components
7V-0368 VALVE & LINES GP-HYD CONTROLS/N 49Z735-1458
Group No: 7V-0368
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0S1594 | 1 BOLT (3/8-16X1-IN) | 4 | |
| 5P1075 | WASHER-HARD (10.2X22.5X3-MM THK) | 4 | |
| 7V0583 | 2 CHANNEL | 1 | |
| 2P1281 | 3 ADAPTER-STRAINER | 4 | |
| 7F2050 | LOCKNUT (3/4-16-THD) | 4 | |
| 5V9354 | 4 U-BOLT | 1 | |
| 4J8265 | 5 NUT (3/8-16-THD) | 2 | |
| 9M4594 | 6 SPACER (0.406X0.875X0.75-IN THK) | 2 | |
| 7B3235 | 7 BOLT (1/2-13X1.375-IN) | 4 | |
| 5P1076 | 8 WASHER-HARD (13.5X30X4-MM THK) | 4 | |
| 2P1278 | 9 ADAPTER | 4 | |
| 2P1279 | LOCKNUT (9/16-18-THD) | 4 | |
| 2V3047 | 10 HOSE AS | 1 | |
| 0S1585 | 11 BOLT (1/2-13X1.5-IN) | 16 | |
| 5P8245 | WASHER-HARD (13.5X25.5X3-MM THK) | 16 | |
| 1P4582 | 12 FLANGE-HALF | 8 | |
| 4J0527 | SEAL-O-RING | 4 | |
| 2V3048 | 13 HOSE AS | 1 | |
| 9J4114 | 14 VALVE GP-MANIFOLD & RELIEF (MAIN) | 1 | |
| 3V7747 | 15 BRACKET AS | 1 | |
| 0S1566 | 16 BOLT (5/8-11X1.5-IN) | 4 | |
| 5P8247 | WASHER-HARD (17X32X3.5-MM THK) | 4 | |
| 3V0752 | 17 HOSE AS | 1 | |
| 3V6962 | 18 ADAPTER | 4 | |
| 1P3705 | 19 SEAL-RECTANGULAR | 10 | |
| 0S1585 | 20 BOLT (1/2-13X1.5-IN) | 32 | |
| 5P8077 | 21 FLANGE-HALF | 4 | |
| 8S9092 | 22 BOLT (5/8-11X2.25-IN) | 8 | |
| 5P8247 | WASHER-HARD (17X32X3.5-MM THK) | 8 | |
| 3V6961 | 23 ADAPTER | 4 | |
| 9T1482 | 24 VALVE GP-CONTROL | 1 | |
| 8M0506 | 25 ADAPTER-O-RING | 8 | |
| 3J1907 | 26 SEAL-O-RING | 12 | |
| 2V9285 | 27 TUBE AS | 4 | |
| 2V9291 | 28 TUBE AS | 1 | |
| 2V9284 | 29 TUBE AS | 4 | |
| 0530700 | 30 TEE-SWIVEL (FLARED) | 1 | |
| 5V9306 | 31 HOSE AS | 3 | |
| 6M6853 | 32 TEE-O-RING | 1 | |
| 8D7564 | 33 INSERT | 2 | |
| 5V9307 | 34 HOSE AS | 1 | |
| 3V0752 | 35 HOSE AS | 1 | |
| 2R6806 | 36 CONNECTOR | 2 | |
| 8M0547 | 37 ELBOW-FLARED (SWIVEL) | 4 | |
| 0321270 | 38 TEE | 2 | |
| 6G1454 | 39 HOSE AS | 2 | |
| 3V2758 | 40 HOSE AS | 2 | |
| 2R6806 | 41 CONNECTOR | 3 | |
| 3J1907 | 42 SEAL-O-RING | 13 | |
| 5M2894 | 43 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 9S4191 | 44 PLUG (9/16-18-THD) | 8 | |
| 0307947 | 45 ADAPTER-ELBOW | 1 | |
| 2V9294 | 46 TUBE AS | 1 | |
| 6K9194 | 47 ELBOW | 3 | |
| 0308194 | 48 CONNECTOR | 2 | |
| 2M9780 | 49 SEAL-O-RING | 3 | |
| 0321270 | 50 TEE | 2 | |
| 8J2602 | 51 VALVE GP-SELECTOR | 1 | |
| 0L1143 | 52 BOLT (3/8-16X2.5-IN) | 3 | |
| 7B3235 | 53 BOLT (1/2-13X1.375-IN) | 4 | |
| 7D1649 | 54 WASHER-HARD (13.5X32X5-MM THK) | 4 | |
| 8S9092 | 55 BOLT (5/8-11X2.25-IN) | 8 | |
| 5P8247 | WASHER-HARD (17X32X3.5-MM THK) | 8 | |
| 5P8077 | 56 FLANGE-HALF | 4 | |
| 8S9092 | BOLT (5/8-11X2.25-IN) | 2 | |
| 5V9025 | 57 TUBE AS | 1 | |
| 8V1483 | 58 TUBE AS | 2 | |
| 8M0505 | 59 ADAPTER | 2 | |
| 8M0547 | 60 ELBOW-FLARED (SWIVEL) | 2 | |
| 3K0360 | 61 SEAL-O-RING | 8 | |
| 0S1566 | 62 BOLT (5/8-11X1.5-IN) | 4 | |
| 5P8247 | WASHER-HARD (17X32X3.5-MM THK) | 4 | |
| 2V9109 | 63 PLATE | 2 | |
| 0307948 | 64 ELBOW | 6 | |
| 8V1482 | 65 TUBE AS | 2 | |
| 9S4190 | 66 PLUG-O-RING (7/8-14-THD) | 1 | |
| 5V9023 | 67 TUBE AS | 1 | |
| 5V9024 | 68 TUBE AS | 1 | |
| 1U0423 | 69 VALVE-CHECK | 1 | |
| 5V9016 | 70 PLATE | 1 | |
| 1A2029 | 71 BOLT (3/8-16X1.125-IN) | 2 | |
| 1D4541 | 72 BOLT (5/16-18X3-IN) | 2 | |
| 1D4716 | NUT-FULL (5/16-18-THD) | 2 | |
| 9M1974 | WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 1U1100 | 73 VALVE GP-PRESSURE REDUCING | 1 | |
| 5V8976 | 74 PLATE | 1 | |
| 0S0509 | BOLT (3/8-16X0.75-IN) | 2 | |
| 2P1278 | 75 ADAPTER | 1 | |
| 2P1279 | LOCKNUT (9/16-18-THD) | 1 |
