System And Components
7C4667 DRIVE GP-FAN BELTFOR USE WITH FOLDED CORE COOLING SYSTEM
Group No: 7C4667
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8L5213 | 1 BOLT | 1 | |
| 1D4717 | 2 NUT | 1 | |
| 6N2538 | 3 BRACKET-FAN ADJUSTMENT | 1 | |
| 0S1594 | 4 BOLT | 2 | |
| 6N2547 | 5 ADAPTER-FAN BRACKET | 1 | |
| 9L0553 | 6 STUD-TAPERLOCK | 4 | |
| 6N7688 | 7 BRACKET AS-FAN | 1 | |
| 1P9946 | SHAFT-FAN | 1 | |
| 4N0684 | PIN-DOWEL | 1 | |
| 1D4719 | 8 NUT | 4 | |
| 7D1649 | WASHER | 4 | |
| 5S9062 | 9 SPACER | 1 | |
| 7N8827 | 10 HUB | 1 | |
| 5S2106 | 11 SEAL-LIP TYPE | 1 | |
| 3B8489 | 12 FITTING-GREASE | 1 | |
| 7N2900 | 13 WASHER-RETAINING | 1 | |
| 5P7979 | 14 BOLT-SELF LOCKING | 2 | |
| 5M6214 | 15 PLUG-PIPE | 1 | |
| 3L1425 | 16 BALL BEARING | 1 | |
| 4L9564 | 17 SEAL-O-RING | 1 | |
| 0L2070 | 18 BOLT | 6 | |
| 2P2243 | 19 SPACER | 1 | |
| 8H9789 | 20 BALL BEARING | 1 |
