System And Components
1W5313 FAN DRIVE GROUP-SUCTIONFOR USE WITH 1200 RPM ENGINE
Group No: 1W5313
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8N5125 | 1 BRACKET AS | 1 | |
| 5S2106 | 2 SEAL-LIP TYPE | 1 | |
| 7N8827 | 3 HUB | 1 | |
| 2D4867 | 4 FITTING-HYDRAULIC | 1 | |
| 9L6642 | 5 V-BELT SET | 1 | |
| 9F4446 | 6 SEAL-O-RING | 1 | |
| 5S7264 | 7 WASHER-RETAINING | 1 | |
| 1H5403 | BOLT 50.8MM(2IN.)LG. | 2 | |
| 7N2900 | WASHER-RETAINING | 1 | |
| 5P7979 | BOLT-SELF LOCKING | 2 | |
| 1B5174 | 8 PLUG-PIPE | 1 | |
| 4B4550 | 9 FITTING-RELIEF | 1 | |
| 3L1425 | 10 BALL BEARING | 1 | |
| 4N3123 | 11 ADAPTER-FAN | 1 | |
| 7N3947 | 12 PULLEY-FAN | 1 | |
| 0T0065 | 13 BOLT | 6 | |
| 2P2243 | 14 SPACER | 1 | |
| 8H9789 | 15 BALL BEARING | 1 | |
| 8L5213 | 16 BOLT | 1 | |
| 1D4717 | NUT | 1 | |
| 8N4605 | 17 ADAPTER-FAN BRACKET | 1 | |
| 4S7523 | 18 STUD-TAPERLOCK | 4 | |
| 1F7960 | WASHER | 4 | |
| 1D4719 | NUT | 4 | |
| 0S1594 | 19 BOLT | 2 | |
| 6N2538 | 20 BRACKET-FAN ADJUSTMENT | 1 | |
| 5S9062 | 21 SPACER | 1 |
