System And Components
1W1053 CARTRIDGE GP-TURBOCHARGER*RPART OF 7W8480 & 7C2485 TURBOCHARGERS
Group No: 1W1053
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7N0239 | 1 NUT-TURBO COMPRESSOR | 1 | |
| 7N9565 | 2 WHEEL-COMPRESSOR | 1 | |
| 5S4556 | 3 INSERT | 1 | |
| 5S4546 | 4 RING-RETAINING | 1 | |
| 5P5757 | 5 SEAL-O-RING | 1 | |
| 5S4554 | 6 SEAL-O-RING | 1 | |
| 4N7597 | 7 BEARING AS | 1 | |
| 4M6983 | 8 RING-RETAINING | 4 | |
| 5S4557 | 9 BEARING | 2 | |
| 1W1055 | 10 HOUSING AS-BEARING | 1 | |
| 5S5199 | 11 PIN-GROOVE | 1 | |
| 4N9556 | 12 SHROUD | 1 | |
| 9S8993 | 13 WHEEL AS-TURBINE | 1 | |
| 5S4551 | 14 SLEEVE-OIL CONTROL | 1 | |
| 7N2856 | 15 RING-SEAL | 1 | |
| 5S4549 | 16 DEFLECTOR-OIL | 1 | |
| 4N7609 | 17 RING-THRUST | 2 | |
| 5S4547 | 18 SLEEVE-SPACER | 1 | |
| 4M8013 | 19 RING-PISTON | 2 | |
| 8S9222 | 20 SLEEVE | 1 | |
| 4M6990 | 21 RING-SNAP | 1 | |
| 2W0725 | KIT-CARTRIDGE (CARTRIDGE REPAIR) | 1 | |
| 9S1180 | NAMEPLATE | 1 | |
| 8H3710 | SCREW-TAPPING | 2 |
