System And Components
1W7516 LINES GP-AIRS/N 81Z1-3557
Group No: 1W7516
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5P5700 | 1 SEAL-O-RING | 8 | |
| 4N8523 | 2 PIPE-OUTLET | 1 | |
| 3B1915 | 3 BOLT | 8 | |
| 5M2894 | 4 WASHER | 8 | |
| 4N1320 | 5 GASKET-ADAPTER | 2 | |
| 3N3368 | 6 PIPE-EXHAUST | 1 | |
| 1A2029 | 7 BOLT | 2 | |
| 2W0796 | 8 SUPPORT-EXHAUST TUBE | 1 | |
| 1W7515 | 9 COUPLING | 2 | |
| 0S1608 | 10 BOLT | 2 | |
| 4N1849 | 11 PIPE-AIR | 2 | |
| 4N8677 | 12 PIPE-OUTLET | 1 | |
| 3J5389 | 13 PLUG | 2 | |
| 5B7890 | 14 PLUG-PIPE | 2 | |
| 1A5183 | 15 BOLT 120MM(4.75IN)LONG | 3 | |
| 2W0892 | 16 TUBE-EXHAUST-RH | 1 | |
| 8N0879 | 17 CLAMP | 4 | |
| 8N0878 | 18 CLAMP | 2 | |
| 8N0886 | SEAL-EXHAUST | 2 | |
| 8N0887 | 19 TUBE-EXHAUST | 2 | |
| 8N8629 | 20 ELBOW-EXHAUST | 1 | |
| 6N6734 | 21 SUPPORT-HOUSING-RH | 1 | |
| 0S1619 | 22 BOLT | 4 | |
| 1D4717 | 23 NUT | 3 | |
| 9F8999 | 24 BOLT | 1 | |
| 5B2638 | 25 BOLT 133.35MM(5.25IN)LONG | 2 | |
| 6N7152 | 26 SUPPORT-ELBOW | 1 | |
| 5P5855 | 27 BOLT-12 POINT HEAD | 2 | |
| 2M0849 | WASHER | 2 | |
| 1W0481 | 28 RING-EXHAUST SEAL | 2 | |
| 6N6733 | 29 SUPPORT-HOUSING-LH | 1 | |
| 0S1591 | 30 BOLT 38.1MM(1.5IN)LONG | 4 | |
| 2W0893 | 31 TUBE-EXHAUST-LH | 1 | |
| 8N8626 | 32 ELBOW-EXHAUST | 1 | |
| 0L1143 | 33 BOLT 63.5MM(2.5IN)LONG | 4 | |
| 1D4719 | 34 NUT | 4 | |
| 6N7149 | 35 SUPPORT-ELBOW | 1 | |
| 0S1587 | 36 BOLT | 4 | |
| 1S9130 | 37 STUD | 1 | |
| 0L2070 | 38 BOLT | 2 | |
| 1A5964 | 39 BOLT | 1 |
