System And Components
4W7649 AIR LINES GROUPS/N 81Z3481-UP
Group No: 4W7649
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8N8348 | 1 CLAMP-HOSE | 4 | |
| 1N4474 | 2 TUBE AS-OUTLET | 1 | |
| 3B1915 | 3 BOLT | 8 | |
| 5M2894 | 4 WASHER | 8 | |
| 4N1320 | 5 GASKET-ADAPTER | 2 | |
| 3N3368 | 6 PIPE-EXHAUST | 1 | |
| 1A2029 | 7 BOLT | 2 | |
| 2W0796 | 8 SUPPORT-EXHAUST TUBE | 1 | |
| 1W7515 | 9 COUPLING | 2 | |
| 0S1608 | 10 BOLT | 2 | |
| 4W7380 | 11 HOSE | 2 | |
| 1N3180 | 12 TUBE AS-OUTLET | 1 | |
| 7W6492 | 13 PLUG-PIPE | 2 | |
| 3E7428 | 14 PLUG-PIPE | 2 | |
| 1A5183 | 15 BOLT 120MM(4.75IN)LG | 3 | |
| 6I2855 | 16 TUBE AS | 1 | |
| 8N0879 | 17 CLAMP | 4 | |
| 1A5964 | 18 BOLT | 1 | |
| 0L2070 | 19 BOLT | 2 | |
| 8N8629 | 20 ELBOW-EXHAUST | 1 | |
| 6N6734 | 21 SUPPORT-HOUSING-RH | 1 | |
| 0S1619 | 22 BOLT 76.20MM(3.00IN)LG | 4 | |
| 0L1352 | BOLT 82.55MM(3.25IN)LG | 4 | |
| 9S8752 | 23 NUT-FULL | 3 | |
| 9F8999 | 24 BOLT | 1 | |
| 5B2638 | 25 BOLT 133.35MM(5.25IN)LG | 2 | |
| 6N7152 | 26 SUPPORT-ELBOW | 1 | |
| 5P5855 | 27 BOLT-12 POINT HEAD | 2 | |
| 5P8245 | WASHER | 2 | |
| 2M8411 | 28 STUD | 1 | |
| 6N6733 | 29 SUPPORT-HOUSING-LH | 1 | |
| 0S1591 | 30 BOLT 38.10MM(1.50IN)LG | 4 | |
| 6I2854 | 31 TUBE AS | 1 | |
| 8N8626 | 32 ELBOW-EXHAUST | 1 | |
| 0L1143 | 33 BOLT 63.50MM(2.50IN)LG | 4 | |
| 0T0573 | BOLT 69.85MM(2.75IN)LG | 3 | |
| 1F7958 | 34 NUT-FULL | 4 | |
| 6N7149 | 35 SUPPORT-ELBOW | 1 | |
| 0S1587 | 36 BOLT | 4 |
