System And Components
4W9008 FUEL INJECTION LINES GROUPS/N 81Z4971-UP
Group No: 4W9008
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7N0654 | 1 BOLT AS | 24 | |
| 1B7182 | BOLT | 1 | |
| 3B4505 | LOCKWASHER | 1 | |
| 5P6006 | 2 TUBE .1 M(3.94 IN.) | 1 | |
| 6N2944 | 3 PLUG | 4 | |
| 6N4721 | 4 BRACKET | 2 | |
| 7N0661 | 5 CLAMP | 2 | |
| 7N0662 | 6 DAMPER | 4 | |
| 7N0669 | 7 CLAMP | 2 | |
| 6N0925 | 8 CLAMP | 2 | |
| 7N0813 | 9 DAMPER | 4 | |
| 8S3997 | 10 CLAMP | 1 | |
| 7N0663 | 11 CLAMP | 1 | |
| 7N0664 | 12 DAMPER | 2 | |
| 4W3207 | 13 LINE AS-FUEL INJ (NO 7) | 1 | |
| 4W3209 | 14 LINE AS-FUEL INJ (NO 9) | 1 | |
| 4W3205 | 15 LINE AS-FUEL INJ (NO 5) | 1 | |
| 4W3201 | 16 LINE AS-FUEL INJ (NO 1) | 1 | |
| 6V4314 | 17 SEAL-O-RING | 1 | |
| 1S0004 | 18 SEAL-O-RING | 2 | |
| 0S1591 | 19 BOLT | 4 | |
| 5M2894 | WASHER | 4 | |
| 0688438 | SPACER | 4 | |
| 4W3211 | 20 LINE AS-FUEL INJ (NO 11) | 1 | |
| 4W3203 | 21 LINE AS-FUEL INJ (NO 3) | 1 | |
| 4W3206 | 22 LINE AS-FUEL INJ (NO 6) | 1 | |
| 4W3212 | 23 LINE AS-FUEL INJ (NO 12) | 1 | |
| 4W3202 | 24 LINE AS-FUEL INJ (NO 2) | 1 | |
| 4W3210 | 25 LINE AS-FUEL INJ (NO 10) | 1 | |
| 4W3208 | 26 LINE AS-FUEL INJ (NO 8) | 1 | |
| 4W3204 | 27 LINE AS-FUEL INJ (NO 4) | 1 | |
| 7N0665 | 28 CLAMP | 1 | |
| 6N2751 | 29 CLAMP | 2 | |
| 7N0671 | 30 DAMPER | 4 | |
| 7N0814 | 31 DAMPER | 2 | |
| 7N0670 | 32 BRACKET | 1 | |
| 7N0666 | 33 CLAMP 91.94MM(3.62 IN.) | 1 | |
| 6N4720 | CLAMP 63.50MM(2.50 IN.) | 1 | |
| 5B1484 | 34 NUT | 12 | |
| 7W2315 | 35 RETAINER | 12 | |
| 5P8119 | 36 SEAL-O-RING | 12 | |
| 2W8142 | 37 LINE AS-FUEL INJ | 12 | |
| 1H1023 | SEAL-O-RING | 1 | |
| 4W7019 | 38 NOZZLE AS | 12 | |
| 9L9098 | 39 SEAL-CARBON STOP | 1 | |
| 2W1230 | 40 SCREW-BUTTON HEAD | 1 | |
| 8T0659 | WASHER-SEALING | 1 | |
| 1S8947 | 41 SEAL-O-RING | 1 | |
| 6M5062 | 42 SEAL-O-RING | 1 |
