System And Components
8N-8709 CONVERSION GP-RADIATORS/N 50W6041-6756
Group No: 8N-8709
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4N1418 | 1 GASKET-RADIATOR INLET | 2 | |
| 7N4051 | 2 STRIP | 2 | |
| 6N4942 | 3 GASKET-TOP TANK | 1 | |
| 6N4941 | 4 GASKET-RADIATOR | 2 | |
| 7N4054 | 5 STRIP | 4 | |
| 4W4987 | 6 CORE AS-RADIATOR | 1 | |
| 8N5411 | 7 DAMPER AS | 2 | |
| 7N8441 | 8 BRACKET AS | 4 | |
| 0S1594 | 9 BOLT (3/8-16X1-IN) | 24 | |
| 7M7794 | 10 STUD-WELD (9.4X21.5X25.5-MM) | 24 | |
| 9S8752 | NUT-FULL (3/8-16-THD) | 24 | |
| 8N8710 | 11 ANGLE AS | 2 | |
| 0S1590 | 12 BOLT (3/8-16X2-IN) | 28 | |
| 7N4039 | 13 STRIP | 2 | |
| 4N1419 | 14 GASKET-OUTLET | 1 | |
| 0S1591 | 15 BOLT (3/8-16X1.5-IN) | 36 | |
| 8N0335 | 16 CHANNEL AS | 2 | |
| 5M2894 | 17 WASHER-HARD (10.2X18.5X2.5-MM THK) | 48 | |
| 0L2070 | 18 BOLT (3/8-16X2.25-IN) | 22 |
