System And Components
8R-0585 LINES GP-POWER TRAIN OILS/N 50W10581-UP
Group No: 8R-0585
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1P4578 | 1 FLANGE-HALF | 12 | |
| 4J0522 | 2 SEAL-O-RING | 7 | |
| 8T8916 | 3 BOLT (7/16-14X1.5-IN) | 16 | |
| 8T5360 | 4 WASHER (12X22.5X2.5-MM THK) | 24 | |
| 2V5043 | 5 HOSE AS | 1 | |
| 1P4579 | 6 FLANGE-HALF | 4 | |
| 8T8919 | 7 BOLT (1/2-13X1.75-IN) | 8 | |
| 8T4223 | 8 WASHER-HARD (13.5X25.5X3-MM THK) | 16 | |
| 2V2934 | 9 HOSE AS | 1 | |
| 5P2566 | 10 BOLT (1/2-13X1.5-IN) | 8 | |
| 7X0313 | 11 BOLT (7/16-14X2.75-IN) | 4 | |
| 7X0308 | 12 BOLT (7/16-14X1.375-IN) | 4 | |
| 8R0247 | 13 SPACER | 1 | |
| 4J0527 | 14 SEAL-O-RING | 2 | |
| 2V5038 | 15 HOSE AS | 1 | |
| 4V1776 | 16 HOSE AS | 1 | |
| 8C3447 | 17 CAP-DUST | 1 | |
| 8C3446 | 18 VALVE-SAMPLING | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 6W5619 | 19 HOSE AS | 1 | |
| 8R0587 | 20 HOSE AS | 1 | |
| 6V8397 | 21 SEAL-O-RING | 4 | |
| 8R0586 | 22 TUBE AS | 1 | |
| 6V8636 | 23 CONNECTOR | 1 | |
| 3J1907 | 24 SEAL-O-RING | 4 | |
| 1P4582 | 25 FLANGE-HALF | 4 | |
| 4J0527 | SEAL-O-RING | 2 | |
| 6P6569 | 26 VALVE GP-SEQUENCE & PRESS CONT | 1 | |
| 4L6459 | BOLT (3/8-16X2.5-IN) | 3 | |
| 8M4447 | SEAL-O-RING | 1 | |
| 8M4988 | SEAL-O-RING | 3 | |
| 6V8724 | 27 ELBOW (90 DEGREE) | 3 | |
| 6V1867 | 28 CLIP (SLOT) | 1 | |
| 6V1868 | CLIP (TAB) | 1 | |
| 8C4436 | 29 BOLT (1/2-13X1.375-IN) | 1 | |
| 7X0584 | WASHER-HARD (13.5X20.5X2-MM THK) | 2 | |
| 6V8188 | NUT (1/2-13-THD) | 1 | |
| 8T4223 | 30 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 2V2965 | 31 BRACKET | 1 | |
| 5P2566 | 32 BOLT (1/2-13X1.5-IN) | 1 | |
| 6V1869 | 33 GROMMET (65-MM ID) | 1 | |
| 8B6127 | 34 CLIP (LOOP) | 1 |
