System And Components
8V-1004 LINES GP-POWER TRAIN OILS/N 50W6041-7507
Group No: 8V-1004
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2V2934 | 1 HOSE AS | 1 | |
| 4J0522 | 4 SEAL-O-RING | 7 | |
| 0T0772 | 5 BOLT (7/16-14X1.5-IN) | 16 | |
| 1P4578 | 6 FLANGE-HALF | 12 | |
| 2V5043 | 7 HOSE AS | 1 | |
| 2V5038 | 11 HOSE AS | 1 | |
| 2V2931 | 15 HOSE AS | 1 | |
| 4J0524 | 19 SEAL-O-RING | 2 | |
| 0S1587 | 20 BOLT (1/2-13X1.75-IN) | 8 | |
| 5P8245 | WASHER-HARD (13.5X25.5X3-MM THK) | 8 | |
| 1P4579 | 21 FLANGE-HALF | 4 | |
| 5P8244 | 22 WASHER-HARD (12X22.5X2.5-MM THK) | 26 | |
| 3H5368 | 23 BOLT (7/16-14X1.375-IN) | 4 | |
| 7V8532 | 24 SPACER | 1 | |
| 1D4556 | 25 BOLT (7/16-14X2.75-IN) | 4 | |
| 1A1460 | 26 BOLT (1/2-13X2-IN) | 5 | |
| 5P8245 | 27 WASHER-HARD (13.5X25.5X3-MM THK) | 10 | |
| 2V2991 | 28 TUBE AS | 1 | |
| 3V0730 | 29 HOSE AS | 1 | |
| 2R6806 | 32 CONNECTOR | 1 | |
| 3J1907 | 33 SEAL-O-RING | 4 | |
| 0307947 | 34 ADAPTER-ELBOW | 3 | |
| 2V2793 | 35 CLIP | 2 | |
| 2V2965 | 36 BRACKET | 1 | |
| 2V2963 | 37 HOSE | 1 | |
| 5P4868 | 38 CLAMP-HOSE | 2 | |
| 0L1351 | 39 BOLT (3/8-16X0.875-IN) | 2 | |
| 5P8244 | WASHER-HARD (12X22.5X2.5-MM THK) | 2 | |
| 6F7047 | 40 WASHER (16.7X27X6-MM THK)(PLAIN) | 1 | |
| 1D4569 | 41 BOLT (1/2-13X4.25-IN) | 4 | |
| 2V5036 | 42 BRACKET AS | 1 | |
| 2V2990 | 43 TUBE AS | 1 | |
| 2V9667 | 44 TUBE AS | 1 | |
| 1P3709 | 45 SEAL-RECTANGULAR | 2 | |
| 1D4717 | 46 NUT (3/8-16-THD) | 1 | |
| 6P6569 | 47 VALVE GP-SEQUENCE & PRESS CONT | 1 | |
| 8M4447 | SEAL-O-RING | 1 | |
| 0L1143 | BOLT (3/8-16X2.5-IN) | 3 | |
| 8M4988 | SEAL-O-RING | 3 | |
| 0S1585 | 48 BOLT (1/2-13X1.5-IN) | 1 | |
| 8B6127 | 49 CLIP (LOOP) | 1 |
