System And Components
8V-1004 LINES GP-POWER TRAIN OILS/N 50W7508-7809
Group No: 8V-1004
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2V2934 | 1 HOSE AS | 1 | |
| 8S9355 | HOSE | ||
| 6V1404 | STEM AS (STRAIGHT) | 1 | |
| 7S0575 | 2 STEM AS (90) | 1 | |
| 3S7252 | 3 SLEEVE | 2 | |
| 4J0522 | 4 SEAL-O-RING | 7 | |
| 0T0772 | 5 BOLT (7/16-14X1.5-IN) | 16 | |
| 1P4578 | 6 FLANGE-HALF | 12 | |
| 2V5043 | 7 HOSE AS | 1 | |
| 8S9355 | HOSE | ||
| 7S0575 | 8 STEM AS (90) | 1 | |
| 6V1404 | 9 STEM AS (STRAIGHT) | 1 | |
| 3S7252 | 10 SLEEVE | 2 | |
| 2V5038 | 11 HOSE AS | 1 | |
| 8S9348 | HOSE | ||
| 5S3779 | 12 STEM AS (STRAIGHT) | 1 | |
| 3S8570 | 13 STEM AS (45) | 1 | |
| 3S7116 | 14 SLEEVE | 2 | |
| 6W6339 | 15 HOSE AS | 1 | |
| 3H5368 | 16 BOLT (7/16-14X1.375-IN) | 4 | |
| 7V8532 | 17 SPACER | 1 | |
| 1D4556 | 18 BOLT (7/16-14X2.75-IN) | 4 | |
| 4J0524 | 19 SEAL-O-RING | 2 | |
| 0S1587 | 20 BOLT (1/2-13X1.75-IN) | 8 | |
| 5P8245 | WASHER-HARD (13.5X25.5X3-MM THK) | 8 | |
| 1P4579 | 21 FLANGE-HALF | 4 | |
| 5P8244 | 22 WASHER-HARD (12X22.5X2.5-MM THK) | 26 | |
| 0S1585 | 23 BOLT (1/2-13X1.5-IN) | 9 | |
| 5P8245 | 24 WASHER-HARD (13.5X25.5X3-MM THK) | 9 | |
| 6W5619 | 25 HOSE AS | 1 | |
| 3V0730 | 26 HOSE AS | 1 | |
| 2P5943 | HOSE | ||
| 4S5414 | 27 SLEEVE | 2 | |
| 8S6417 | 28 COUPLING AS | 2 | |
| 2R6806 | 29 CONNECTOR | 1 | |
| 3J1907 | 30 SEAL-O-RING | 4 | |
| 0307947 | 31 ADAPTER-ELBOW | 3 | |
| 4J0527 | 32 SEAL-O-RING | 2 | |
| 2V2965 | 33 BRACKET | 1 | |
| 1P4582 | 34 FLANGE-HALF | 4 | |
| 6V1869 | 35 GROMMET (65-MM ID) | 1 | |
| 6V1868 | 36 CLIP (TAB) | 1 | |
| 6V1867 | CLIP (SLOT) | 1 | |
| 1D4719 | 37 NUT-FULL (1/2-13-THD) | 1 | |
| 7B3235 | 38 BOLT (1/2-13X1.375-IN) | 1 | |
| 5P7213 | 39 WASHER-HARD (13.5X20.5X2-MM THK) | 2 | |
| 8B6127 | 40 CLIP (LOOP) | 1 | |
| 2V9667 | 41 TUBE AS | 1 | |
| 6P6569 | 42 VALVE GP-SEQUENCE & PRESS CONT | 1 | |
| 8M4447 | SEAL-O-RING | 1 | |
| 0L1143 | BOLT (3/8-16X2.5-IN) | 3 | |
| 8M4988 | SEAL-O-RING | 3 |
