System And Components
8V-1004 LINES GP-POWER TRAIN OILS/N 50W7810-9009
Group No: 8V-1004
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1P4578 | 1 FLANGE-HALF | 12 | |
| 8T7212 | 2 SEAL | 7 | |
| 0T0772 | 3 BOLT (7/16-14X1.5-IN) | 16 | |
| 5P8244 | 4 WASHER-HARD (12X22.5X2.5-MM THK) | 24 | |
| 2V5043 | 5 HOSE AS | 1 | |
| 2V2934 | 6 HOSE AS | 1 | |
| 3H5368 | 7 BOLT (7/16-14X1.375-IN) | 4 | |
| 7V8532 | 8 SPACER | 1 | |
| 8T7214 | 9 SEAL (54.55-MM ID) | 2 | |
| 2V5038 | 10 HOSE AS | 1 | |
| 1P4579 | 11 FLANGE-HALF | 4 | |
| 0S1587 | 12 BOLT (1/2-13X1.75-IN) | 8 | |
| 5P8245 | 13 WASHER-HARD (13.5X25.5X3-MM THK) | 16 | |
| 0S1585 | 14 BOLT (1/2-13X1.5-IN) | 8 | |
| 1D4556 | 15 BOLT (7/16-14X2.75-IN) | 4 | |
| 4V1776 | 16 HOSE AS | 1 | |
| 6W5619 | 17 HOSE AS | 1 | |
| 3V0730 | 18 HOSE AS | 1 | |
| 2R6806 | 19 CONNECTOR | 1 | |
| 3J1907 | 20 SEAL-O-RING | 4 | |
| 1P4582 | 21 FLANGE-HALF | 4 | |
| 8T7213 | SEAL (64.09-MM ID) | 2 | |
| 6P6569 | 22 VALVE GP-SEQUENCE & PRESS CONT | 1 | |
| 0L1143 | BOLT (3/8-16X2.5-IN) | 3 | |
| 8M4447 | SEAL-O-RING | 1 | |
| 8T7129 | SEAL | 3 | |
| 0307947 | 23 ADAPTER-ELBOW | 3 | |
| 6V1867 | 24 CLIP (SLOT) | 1 | |
| 6V1868 | CLIP (TAB) | 1 | |
| 7B3235 | 25 BOLT (1/2-13X1.375-IN) | 1 | |
| 5P7213 | WASHER-HARD (13.5X20.5X2-MM THK) | 2 | |
| 1D4719 | NUT-FULL (1/2-13-THD) | 1 | |
| 5P8245 | 26 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 2V2965 | 27 BRACKET | 1 | |
| 0S1585 | 28 BOLT (1/2-13X1.5-IN) | 1 | |
| 6V1869 | 29 GROMMET (65-MM ID) | 1 | |
| 8B6127 | 30 CLIP (LOOP) | 1 | |
| 2V9667 | 31 TUBE AS | 1 |
