System And Components
8V-1413 CONTROL GP-SERVICE BRAKES/N 50W6264-7961
Group No: 8V-1413
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0S1619 | 1 BOLT (3/8-16X3-IN) | 2 | |
| 2M6835 | PIPE | 2 | |
| 5M2894 | 2 WASHER-HARD (10.2X18.5X2.5-MM THK) | 15 | |
| 0S1588 | 3 BOLT (3/8-16X1.25-IN) | 3 | |
| 2V3767 | 4 PLATE AS | 1 | |
| 5B1983 | BOSS (3/8-16-THD) | 1 | |
| 3T4446 | 5 SWITCH AS-PRESSURE | 1 | |
| 2V3172 | ADAPTER | 1 | |
| 3J7354 | SEAL-O-RING | 2 | |
| 0303978 | CONNECTOR | 1 | |
| 0307947 | 6 ADAPTER-ELBOW | 2 | |
| 3J1907 | 7 SEAL-O-RING | 4 | |
| 6K9194 | 8 ELBOW | 1 | |
| 2R6806 | 9 CONNECTOR | 2 | |
| 0S1590 | 10 BOLT (3/8-16X2-IN) | 2 | |
| 7K4994 | 11 FLANGE | 1 | |
| 9H6761 | SEAL-O-RING | 1 | |
| 2V5702 | 12 TUBE AS | 1 | |
| 2V4399 | 13 TUBE AS | 1 | |
| 2R6276 | 14 CONNECTOR | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 2V5706 | 15 HOSE AS | 1 | |
| 3S7166 | 16 SLEEVE | 2 | |
| 5S5283 | 17 STEM AS-COLLET (STRAIGHT) | 1 | |
| 8S6389 | 18 COUPLING AS (90) | 1 | |
| 4J0520 | 19 SEAL-O-RING | 1 | |
| 3B1915 | 20 BOLT (3/8-16X1.375-IN) | 4 | |
| 1P4577 | 21 FLANGE-HALF | 2 | |
| 2V6778 | 22 ELBOW | 1 | |
| 9S8005 | 23 PLUG (3/4-16-THD) | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 1D4556 | 24 BOLT (7/16-14X2.75-IN) | 1 | |
| 4S9191 | 25 WASHER (12X22.5X5-MM THK) | 4 | |
| 0T0772 | 26 BOLT (7/16-14X1.5-IN) | 3 | |
| 0S1625 | 27 BOLT (5/8-11X2.5-IN) | 2 | |
| 2S7593 | WASHER-HARD (17X35X5-MM THK) | 2 | |
| 9J8675 | 28 ACCUMULATOR GP-BRAKE | 1 | |
| 2V5707 | 29 MANIFOLD | 1 | |
| 1N7284 | BOLT-12 POINT HEAD (3/8-16X2.5-IN) | 4 | |
| 1P3704 | 30 SEAL-RECTANGULAR | 2 | |
| 9K1242 | 31 CONNECTOR | 1 | |
| 4K1388 | SEAL-O-RING | 1 | |
| 1V2832 | 32 MANIFOLD | 1 | |
| 1P3704 | SEAL-RECTANGULAR | 1 | |
| 2V4400 | 33 TUBE AS | 1 | |
| 0L2070 | 34 BOLT (3/8-16X2.25-IN) | 4 | |
| 5M2894 | 35 WASHER-HARD (10.2X18.5X2.5-MM THK) | 21 | |
| 5M6214 | 36 PLUG (1/8-27 PTF) | 1 | |
| 1V2830 | 37 TUBE AS | 1 | |
| 9S4183 | 38 PLUG (1-1/16-12-THD) | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 1P3703 | 39 SEAL-RECTANGULAR | 2 | |
| 0S1608 | 40 BOLT (3/8-16X3.75-IN) | 4 | |
| 0S1573 | 41 BOLT (1/2-13X4-IN) | 3 | |
| 4T3128 | 42 VALVE GP-BRAKE NEUTRALIZER | 1 | |
| 9J4693 | 43 VALVE GP-ACCUMULATOR CHARGING | 1 | |
| 0307946 | 44 ELBOW | 1 | |
| 3J7354 | 45 SEAL-O-RING | 3 | |
| 2V5705 | 46 TUBE AS | 1 | |
| 0619258 | 47 TEE | 1 | |
| 2R6806 | 48 CONNECTOR | 3 | |
| 3J1907 | 49 SEAL-O-RING | 4 | |
| 0L1351 | 50 BOLT (3/8-16X0.875-IN) | 3 | |
| 0S1571 | 51 BOLT (3/8-16X1.75-IN) | 4 | |
| 8V6877 | 52 BRACKET AS | 1 | |
| 1D4717 | 53 NUT (3/8-16-THD) | 3 | |
| 4K3777 | 54 EYE-ADJUSTMENT | 1 | |
| 9M1311 | NUT-JAM (1/4-28-THD) | 1 | |
| 3G2228 | 55 VALVE GP-BRAKE CONTROL | 1 | |
| 3T4446 | 56 SWITCH AS-PRESSURE | 1 | |
| 2V3172 | ADAPTER | 1 | |
| 6M6853 | 57 TEE-O-RING | 1 | |
| 2V5703 | 58 TUBE AS | 1 | |
| 2P8447 | TEE-UNION | 1 | |
| 8S9089 | 59 BOLT (1/2-13X4.5-IN) | 3 | |
| 1B4572 | 60 BOLT | 2 | |
| 9J4080 | 61 VALVE GP-BRAKE CONTROL | 1 | |
| 2V5704 | 62 TUBE AS | 1 | |
| 0S1588 | 63 BOLT (3/8-16X1.25-IN) | 4 | |
| 0307957 | 64 TEE-FLARED | 1 | |
| 5H4019 | 65 COVER | 1 | |
| 8V3923 | 66 BLOCK | 1 | |
| 7K1308 | 67 SPACER (5-MM THK) | 2 | |
| 8V3924 | 68 BRACKET | 1 | |
| 3V3308 | 69 WASHER-HARD (10.2X20.5X2.5-MM THK) | 1 | |
| 3T1804 | 70 SWITCH AS (BRAKELIGHT) | 1 | |
| 6V8370 | NUT-HEX (3/4-32-THD) | 1 | |
| 2H3922 | LOCKWASHER | 1 | |
| 6V8363 | 71 SCREW (10-32X0.312-IN) | 2 | |
| 8F1434 | LOCKWASHER | 2 | |
| 1B0676 | 72 PIN | 1 | |
| 3B4617 | 73 PIN-COTTER | 4 | |
| 1M1341 | 74 END-YOKE ROD | 1 | |
| 2V7226 | 75 RETAINER | 2 | |
| 5B9079 | NUT-JAM (3/8-24-THD) | 1 | |
| 2V3764 | ROD | 1 | |
| 2P5677 | 76 SPRING | 1 | |
| 2V3769 | 77 PLATE AS | 1 | |
| 0S1594 | 78 BOLT (3/8-16X1-IN) | 3 | |
| 2A1396 | 79 SCREW-ADJUSTMENT | 2 | |
| 1B2578 | NUT (3/8-16-THD) | 2 | |
| 2D9860 | 80 ROD | 1 | |
| 1B4430 | NUT-JAM (1/2-20-THD) | 1 | |
| 8V0014 | 81 ROD END | 1 | |
| 0S0175 | 82 PIN-CLEVIS | 2 | |
| 2V0014 | 83 LEVER | 1 | |
| 1B8706 | 84 KEY-WOODRUFF | 2 | |
| 2V3761 | 85 SHAFT | 1 | |
| 3B1915 | 86 BOLT (3/8-16X1.375-IN) | 2 | |
| 2P9858 | 87 BEARING-ROLLER | 4 | |
| 2V0016 | 88 LEVER | 1 | |
| 6D3787 | 89 BEARING-ROLLER | 1 | |
| 2V0015 | 90 LEVER | 1 | |
| 2V0003 | 91 LEVER | 1 | |
| 9S6465 | 92 BEARING-ROLLER | 1 | |
| 5J5437 | 93 COVER | 1 | |
| 2A0762 | 94 BOLT (1/4-20X0.625-IN) | 2 | |
| 5P0537 | WASHER-HARD (7.2X14.5X2-MM THK) | 2 | |
| 0S1591 | 95 BOLT (3/8-16X1.5-IN) | 4 | |
| 9F8910 | 96 PIN | 1 | |
| 1B4442 | 97 NUT-SLOTTED | 1 | |
| 2V3717 | 98 BRACKET | 1 | |
| 5M2894 | 99 WASHER-HARD (10.2X18.5X2.5-MM THK) | 7 | |
| 4J5325 | 100 PIN | 2 | |
| 3B4607 | PIN-COTTER | 2 | |
| 8V6882 | 101 LINK | 2 | |
| 8V6880 | 102 LEVER AS | 1 | |
| 6P0593 | 103 BEARING-ROLLER | 1 | |
| 0L2119 | 104 WASHER (16.7X30.2X5-MM THK) | 1 | |
| 3B4628 | 105 PIN-COTTER | 1 | |
| 2V7859 | 106 BEARING | 1 | |
| 1K0502 | 107 WASHER (16.3X25.4X1.2-MM THK) | 1 |
