System And Components
8V-1413 CONTROL GP-SERVICE BRAKES/N 50W7962-11307
Group No: 8V-1413
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T7008 | 1 BOLT (3/8-16X3-IN) | 2 | |
| 2M6835 | PIPE | 2 | |
| 8T4896 | 2 WASHER-HARD (10.2X18.5X2.5-MM THK) | 15 | |
| 9B7237 | 3 BOLT (3/8-16X1.25-IN) | 3 | |
| 2V3767 | 4 PLATE AS | 1 | |
| 5B1983 | BOSS (3/8-16-THD) | 1 | |
| 9W2653 | 5 SWITCH AS-PRESSURE | 1 | |
| 7N7779 | SOCKET-CONNECTOR (14-GA TO 18-GA) | 1 | |
| 7N7780 | PIN-CONNECTOR (14-GA TO 18-GA) | 2 | |
| 7N7781 | HOUSING-RECEPTACLE (14-GA TO 18-GA) | 1 | |
| 0307947 | 6 ADAPTER-ELBOW | 2 | |
| 3J1907 | 7 SEAL-O-RING | 5 | |
| 6K9194 | 8 ELBOW | 1 | |
| 2R6806 | 9 CONNECTOR | 2 | |
| 8T2501 | 10 BOLT (3/8-16X2-IN) | 2 | |
| 7K4994 | 11 FLANGE | 1 | |
| 9H6761 | SEAL-O-RING | 1 | |
| 2V5702 | 12 TUBE AS | 1 | |
| 2V4399 | 13 TUBE AS | 1 | |
| 2R6276 | 14 CONNECTOR | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 2V5706 | 15 HOSE AS | 1 | |
| 9C2205 | 16 MANIFOLD | 1 | |
| 1N7284 | BOLT-12 POINT HEAD (3/8-16X2.5-IN) | 4 | |
| 1P3704 | 17 SEAL-RECTANGULAR | 2 | |
| 9J8675 | 18 ACCUMULATOR GP-BRAKE | 1 | |
| 4J0520 | 19 SEAL-O-RING | 1 | |
| 5S7382 | 20 BOLT (3/8-16X1.375-IN) | 4 | |
| 1P4577 | 21 FLANGE-HALF | 2 | |
| 2V6778 | 22 ELBOW | 1 | |
| 9S8005 | 23 PLUG (3/4-16-THD) | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 7X0313 | 24 BOLT (7/16-14X2.75-IN) | 1 | |
| 7X0507 | 25 WASHER-HARD (12X22.5X5-MM THK) | 4 | |
| 8T8916 | 26 BOLT (7/16-14X1.5-IN) | 3 | |
| 8T6871 | 27 BOLT (5/8-11X2.5-IN) | 2 | |
| 7X0515 | WASHER-HARD (17X35X5-MM THK) | 2 | |
| 9X0023 | 28 SWITCH AS-ROLLER | 1 | |
| 6V8370 | NUT-HEX (3/4-32-THD) | 1 | |
| 2H3922 | LOCKWASHER | 1 | |
| 6V8363 | 29 SCREW (10-32X0.312-IN) | 2 | |
| 8F1434 | LOCKWASHER | 2 | |
| 9K1242 | 30 CONNECTOR | 1 | |
| 4K1388 | SEAL-O-RING | 1 | |
| 1V2832 | 31 MANIFOLD | 1 | |
| 1P3704 | SEAL-RECTANGULAR | 1 | |
| 2V4400 | 32 TUBE AS | 1 | |
| 8T9377 | 33 BOLT (3/8-16X2.25-IN) | 4 | |
| 8T4896 | 34 WASHER-HARD (10.2X18.5X2.5-MM THK) | 18 | |
| 5M6214 | 35 PLUG (1/8-27 PTF) | 1 | |
| 1V2830 | 36 TUBE AS | 1 | |
| 6V0421 | 37 PLUG | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 1P3703 | 38 SEAL-RECTANGULAR | 2 | |
| 7X0291 | 39 BOLT (3/8-16X3.75-IN) | 4 | |
| 8T4896 | 40 WASHER-HARD (10.2X18.5X2.5-MM THK) | 18 | |
| 4T3128 | 41 VALVE GP-BRAKE NEUTRALIZER | 1 | |
| 9J4693 | 42 VALVE GP-ACCUMULATOR CHARGING | 1 | |
| 0307946 | 43 ELBOW | 1 | |
| 3J7354 | 44 SEAL-O-RING | 2 | |
| 2V5705 | 45 TUBE AS | 1 | |
| 8C2948 | 46 ADAPTER-TEE | 1 | |
| 2R6806 | 47 CONNECTOR | 2 | |
| 3J1907 | 48 SEAL-O-RING | 5 | |
| 5S7379 | 49 BOLT (3/8-16X0.875-IN) | 3 | |
| 5S7383 | 50 BOLT (3/8-16X1.75-IN) | 4 | |
| 8V6877 | 51 BRACKET AS | 1 | |
| 6V8801 | 52 NUT (3/8-16-THD) | 3 | |
| 5P1075 | WASHER-HARD (10.2X22.5X3-MM THK) | 3 | |
| 4K3777 | 53 EYE-ADJUSTMENT | 1 | |
| 9M1311 | NUT-JAM (1/4-28-THD) | 1 | |
| 3G2228 | 54 VALVE GP-BRAKE CONTROL | 1 | |
| 9W2653 | 55 SWITCH AS-PRESSURE (HYD. OIL) | 1 | |
| 7N7779 | SOCKET-CONNECTOR (14-GA TO 18-GA) | 1 | |
| 7N7780 | PIN-CONNECTOR (14-GA TO 18-GA) | 2 | |
| 7N7781 | HOUSING-RECEPTACLE (14-GA TO 18-GA) | 1 | |
| 6M6853 | 56 TEE-O-RING | 1 | |
| 2V5703 | 57 TUBE AS | 1 | |
| 2P8447 | TEE-UNION | 1 | |
| 7X0332 | 58 BOLT (1/2-13X4.5-IN) | 3 | |
| 7X0336 | 59 BOLT (1/2-13X5.5-IN) | 2 | |
| 9J4080 | 60 VALVE GP-BRAKE CONTROL | 1 | |
| 2V5704 | 61 TUBE AS | 1 | |
| 9B7237 | 62 BOLT (3/8-16X1.25-IN) | 4 | |
| 0307957 | 63 TEE-FLARED | 1 | |
| 5H4019 | 64 COVER | 1 | |
| 8T7211 | SEAL-O-RING | 1 | |
| 8V3923 | 65 BLOCK | 1 | |
| 7K1308 | 66 SPACER (5-MM THK) | 2 | |
| 8V3924 | 67 BRACKET | 1 | |
| 3V3308 | 68 WASHER-HARD (10.2X20.5X2.5-MM THK) | 1 | |
| 1B0676 | 69 PIN | 1 | |
| 3B4617 | 70 PIN-COTTER | 4 | |
| 1M1341 | 71 END-YOKE ROD | 1 | |
| 2V7226 | 72 RETAINER | 2 | |
| 5B9079 | NUT-JAM (3/8-24-THD) | 1 | |
| 2V3764 | ROD | 1 | |
| 2P5677 | 73 SPRING | 1 | |
| 2V3769 | 74 PLATE AS | 1 | |
| 4L6454 | 75 BOLT (3/8-16X1-IN) | 3 | |
| 2A1396 | 76 SCREW-ADJUSTMENT | 2 | |
| 1B2578 | NUT (3/8-16-THD) | 2 | |
| 2D9860 | 77 ROD | 1 | |
| 1B4430 | NUT-JAM (1/2-20-THD) | 1 | |
| 8V0014 | 78 ROD END | 1 | |
| 0S0175 | 79 PIN-CLEVIS | 2 | |
| 2V0014 | 80 LEVER | 1 | |
| 1B8706 | 81 KEY-WOODRUFF | 2 | |
| 2V3761 | 82 SHAFT | 1 | |
| 5S7382 | 83 BOLT (3/8-16X1.375-IN) | 2 | |
| 2P9858 | 84 BEARING-ROLLER | 4 | |
| 2V0016 | 85 LEVER | 1 | |
| 6D3787 | 86 BEARING-ROLLER | 1 | |
| 2V0015 | 87 LEVER | 1 | |
| 2V0003 | 88 LEVER | 1 | |
| 9S6465 | 89 BEARING-ROLLER | 1 | |
| 5J5437 | 90 COVER | 1 | |
| 8T9364 | 91 BOLT (1/4-20X0.625-IN) | 2 | |
| 8T4205 | WASHER-HARD (7.2X14.5X2-MM THK) | 2 | |
| 4L9337 | 92 BOLT (3/8-16X1.5-IN) | 4 | |
| 9F8910 | 93 PIN | 1 | |
| 1B4442 | 94 NUT-SLOTTED | 1 | |
| 2V3717 | 95 BRACKET | 1 | |
| 8T4896 | 96 WASHER-HARD (10.2X18.5X2.5-MM THK) | 7 | |
| 4J5325 | 97 PIN | 2 | |
| 3B4607 | PIN-COTTER | 2 | |
| 8V6882 | 98 LINK | 2 | |
| 8V6880 | 99 LEVER AS | 1 | |
| 6P0593 | 100 BEARING-ROLLER | 1 | |
| 0L2119 | 101 WASHER (16.7X30.2X5-MM THK) | 1 | |
| 3B4628 | 102 PIN-COTTER | 1 | |
| 2V7859 | 103 BEARING | 1 | |
| 1K0502 | 104 WASHER (16.3X25.4X1.2-MM THK) | 1 |
