System And Components
7V-0366 VALVE & LINES GP-HYD CONTROLS/N 50W8074-10273
Group No: 7V-0366
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1P4578 | 1 FLANGE-HALF | 2 | |
| 4J0522 | 2 SEAL-O-RING | 2 | |
| 5V6075 | 3 TUBE AS | 1 | |
| 5V0056 | 4 TUBE AS | 1 | |
| 5V6074 | 5 TUBE AS | 1 | |
| 0307947 | 6 ADAPTER-ELBOW | 4 | |
| 3J1907 | 7 SEAL-O-RING | 11 | |
| 6K9194 | 8 ELBOW | 4 | |
| 2R6806 | 9 CONNECTOR | 5 | |
| 1P3707 | 10 SEAL-RECTANGULAR | 1 | |
| 8T8919 | 11 BOLT (1/2-13X1.75-IN) | 4 | |
| 8T4223 | 12 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 8R8357 | 13 TUBE AS | 1 | |
| 4L6454 | 14 BOLT (3/8-16X1-IN) | 2 | |
| 3V3308 | 15 WASHER-HARD (10.2X20.5X2.5-MM THK) | 2 | |
| 2P7215 | 16 ELBOW | 2 | |
| 2P1278 | 17 ADAPTER | 4 | |
| 2P1279 | 18 LOCKNUT (9/16-18-THD) | 8 | |
| 4V3578 | 19 TUBE AS (MANIFOLD) | 1 | |
| 5V0058 | 20 TUBE AS | 1 | |
| 9S4190 | 21 PLUG-O-RING (7/8-14-THD) | 1 | |
| 2M9780 | 22 SEAL-O-RING | 3 | |
| 8J2602 | 23 VALVE GP-SELECTOR | 1 | |
| 2V7599 | 24 TUBE AS | 1 | |
| 2V7600 | 25 TUBE AS | 1 | |
| 8T9101 | 26 BOLT (3/8-16X2.75-IN) | 3 | |
| 8T4896 | WASHER-HARD (10.2X18.5X2.5-MM THK) | 3 | |
| 0308194 | 27 CONNECTOR | 2 | |
| 2V7603 | 28 TUBE AS | 1 | |
| 3G3310 | 29 VALVE GP | 1 | |
| 8T4835 | 30 BOLT (1/2-13X2-IN) | 2 | |
| 9T1484 | 31 VALVE GP-MAIN CONTROL (2-FUNCTION) | 1 | |
| 7V0317 | 32 BRACKET | 1 | |
| 5M3062 | 33 BOLT (3/8-16X0.75-IN) | 2 | |
| 8T4896 | WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 5V8448 | 34 HOSE AS | 1 | |
| 7X0584 | 35 WASHER-HARD (13.5X20.5X2-MM THK) | 4 | |
| 1U1100 | 36 VALVE GP-PRESSURE REDUCING | 1 | |
| 7V0312 | 37 PLATE | 1 | |
| 5V0057 | 38 TUBE AS | 1 | |
| 8T8912 | 39 BOLT (5/16-18X2.25-IN) | 2 | |
| 6V8189 | NUT (5/16-18-THD) | 2 | |
| 8T4224 | WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 1U0423 | 40 VALVE-CHECK | 1 | |
| 5V0055 | 41 TUBE AS | 1 | |
| 0307955 | 42 TEE-FLARED | 1 | |
| 5P2566 | 43 BOLT (1/2-13X1.5-IN) | 2 | |
| 1P4579 | 44 FLANGE-HALF | 1 | |
| 4J0524 | SEAL-O-RING | 1 | |
| 5P2566 | 45 BOLT (1/2-13X1.5-IN) | 10 | |
| 1P4579 | 46 FLANGE-HALF | 1 | |
| 4J0524 | SEAL-O-RING | 1 | |
| 9C2285 | 47 ADAPTER | 1 | |
| 4L6454 | 48 BOLT (3/8-16X1-IN) | 2 | |
| 8T4896 | 49 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 6W9669 | 50 HOSE AS | 1 | |
| 7X0325 | 51 BOLT (1/2-13X2.5-IN) | 2 | |
| 6V8188 | 52 NUT (1/2-13-THD) | 2 | |
| 1V9331 | 53 TUBE AS | 1 | |
| 5C6565 | 54 BOLT (1/2-13X1.125-IN) | 4 | |
| 8T8916 | 55 BOLT (7/16-14X1.5-IN) | 4 | |
| 8T5360 | WASHER (12X22.5X2.5-MM THK) | 4 | |
| 4V1879 | 56 BRACKET AS | 1 | |
| 9F2978 | NUT-WELD (3/8-16-THD) | 2 | |
| 7X0578 | 57 WASHER-HARD (10.2X32X2.5-MM THK) | 2 | |
| 8T8917 | 58 BOLT (1/2-13X1.25-IN) | 2 | |
| 1V9325 | 59 HOSE AS | 1 | |
| 8T4223 | 60 WASHER-HARD (13.5X25.5X3-MM THK) | 16 | |
| 1P4582 | 61 FLANGE-HALF | 4 | |
| 8T7213 | SEAL (64.09-MM ID) | 2 | |
| 7X0331 | 62 BOLT (1/2-13X4.25-IN) | 4 | |
| 8T4223 | WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 1P3709 | 63 SEAL-RECTANGULAR | 1 | |
| 7B9919 | 64 CLIP | 8 | |
| 9B7237 | 65 BOLT (3/8-16X1.25-IN) | 4 | |
| 7D5962 | 66 BOLT (1/2-13X3.5-IN) | 4 | |
| 4V1076 | SPACER | 4 | |
| 5P1076 | 67 WASHER-HARD (13.5X30X4-MM THK) | 6 | |
| 5V6181 | 68 PLATE AS | 1 | |
| 9F2978 | 69 NUT-WELD (3/8-16-THD) | 13 | |
| 8S8820 | 70 CLIP | 1 |
