System And Components
7G-3481 PRESSURIZER GP-CABS/N 50W6041-99999
Group No: 7G-3481
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6P1296 | 1 SEAL | 2 | |
| 1D4717 | 2 NUT (3/8-16-THD) | 4 | |
| 5P1075 | 3 WASHER-HARD (10.2X22.5X3-MM THK) | 8 | |
| 7G7808 | 4 BRACKET AS | 1 | |
| 9F2978 | NUT-WELD (3/8-16-THD) | 2 | |
| 5N3175 | 5 PLUG-BUTTON | 4 | |
| 4H0411 | 6 PLUG-PROTECTION | 2 | |
| 6P1298 | 7 STRAP-MOUNTING | 1 | |
| 7G4498 | 8 GROMMET | 1 | |
| 1P6550 | 9 WHEEL-BLOWER | 1 | |
| 8P4324 | 10 HOUSING AS | 1 | |
| 8T9364 | 11 BOLT (1/4-20X0.625-IN) | 27 | |
| 5P4115 | 12 WASHER-HARD (7.2X19X2-MM THK) | 41 | |
| 5P7689 | 13 PLUG-BUTTON | 4 | |
| 7G4497 | 14 CASE AS-CAB HEATER | 1 | |
| 9X4218 | 15 MOTOR AS | 1 | |
| 2L8079 | TERMINAL-RING (14-GA TO 16-GA, 3/8-IN SCREW)(RING) | 1 | |
| 5P4571 | TERMINAL-BLADE (14-GA TO 16-GA) | 1 | |
| 5P5908 | 16 SEAL | ||
| 5M3062 | 17 BOLT (3/8-16X0.75-IN) | 4 | |
| 2H4499 | 18 LOCK | 1 | |
| 3P2866 | 19 WHEEL-BLOWER | 1 | |
| 8P4325 | 20 HOUSING AS | 1 | |
| 7G4767 | 21 INSULATION | 1 | |
| 7G4501 | 22 COVER AS | 1 | |
| 1J7581 | NUT-WELD | 2 | |
| 8P7065 | 23 PLUG-BUTTON | 1 | |
| 9G1917 | 24 PLATE AS | 1 | |
| 4S6336 | 25 PLUG-BUTTON | 3 | |
| 5K3546 | 26 PLUG-BUTTON | 1 | |
| 7G4299 | 27 HARNESS AS | 1 | |
| 6V8185 | 28 NUT (1/4-20-THD) | 6 | |
| 3S2093 | 29 STRAP-CABLE | 3 | |
| 2V3216 | 30 CLIP (LOOP) | 1 | |
| 9G1916 | 31 GROMMET | 1 | |
| 6V1322 | 32 BOLT (1/4-20X0.375-IN) | 9 | |
| 8P1291 | 33 PLATE-MOTOR MOUNTING | 2 | |
| 4B2049 | 34 NUT (10-32-THD) | 2 | |
| 9F8125 | 35 LOCKWASHER | 4 | |
| 8L6521 | 36 BOLT (10-32X0.5-IN) | 2 | |
| 4B4274 | WASHER (5.5X13X1.2-MM THK) | 2 | |
| 7T4568 | 37 BRACKET AS | 1 | |
| 9F2978 | NUT-WELD (3/8-16-THD) | 2 | |
| 9X4383 | 38 RESISTOR | 1 | |
| 6V3320 | 39 SCREW-MACHINE (1/4-20X7.5-IN) | 1 | |
| 7H8909 | LOCKNUT (1/4-20-THD) | 1 | |
| 6V1668 | WASHER (6.5X29.1X3-MM THK) | 2 | |
| 6T6708 | WASHER (7X28.6X4.1-MM THK) | 2 | |
| 9G0398 | KIT-MOTOR BRUSH | 1 |
