Assembly
100%

4W-7007 CYLINDER HEAD GPS/N 73W14298-UP

Group No: 4W-7007
Part NumberPart NameQty
7W80711 BRACKET-FUEL PUMP1
3B19152 BOLT (3/8-16X1.375-IN)1
5M28943 WASHER-HARD (10.2X18.5X2.5-MM THK)2
0S16084 BOLT (3/8-16X3.75-IN)1
1A51835 BOLT (3/8-16X4.75-IN)1
5B26386 BOLT (3/8-16X5.25-IN)1
6N67337 SUPPORT-HOUSING (LH)1
7E73128 GASKET-CYLINDER HEAD2
2H37509 BOLT (3/4-16X7.5-IN)40
5H150410 WASHER-HARD (20X33.5X5-MM THK)40
7W224211 CYLINDER HEAD GP2
0L135212 BOLT (3/8-16X3.25-IN)14
0L135213 BOLT (3/8-16X3.25-IN)5
8T676414 PLUG-PIPE (1/8-27-THD)1
4N093215 PLUG-CUP (57.53-MM OD)2
5P006316 PLUG-CUP4
4N725317 GASKET-CHAMBER12
3E677218 SEAL (WATER)48
106179219 STUD-TAPERLOCK (3/8-16X4-IN)24
7X773120 PLUG-PIPE (3/4-14-THD)2
8T676221 PLUG-PIPE (1/2-14-THD)5
8T676222 PLUG-PIPE (1/2-14-THD)1
8T676423 PLUG-PIPE (1/8-27-THD)1
6N673424 SUPPORT-HOUSING (RH)1
5B263825 BOLT (3/8-16X5.25-IN)1
1A518326 BOLT (3/8-16X4.75-IN)1
5M289427 WASHER-HARD (10.2X18.5X2.5-MM THK)3
0S159128 BOLT (3/8-16X1.5-IN)1
8S919129 BOLT (3/8-16X4-IN)2
1W520730 BRACKET-FUEL PUMP1
8M524931 SEAL-O-RING12
100692032 ADAPTER-NOZZLE12
