System And Components
8N-2402 LINES GP-AIRS/N 73W3857-6387
Group No: 8N-2402
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8N2056 | 1 MANIFOLD-INLET | 1 | |
| 0S0509 | 2 BOLT (3/8-16X0.75-IN) | 2 | |
| 8M7145 | 3 WASHER (10.2X28.5X5-MM THK) | 2 | |
| 1W5384 | 4 ELBOW-OUTLET | 1 | |
| 5S1188 | 5 SEAL-O-RING | 2 | |
| 1W5380 | 6 ADAPTER | 1 | |
| 1W5652 | 7 TUBE AS-EXHAUST | 1 | |
| 8N0878 | 8 CLAMP | 2 | |
| 8N0886 | 9 SEAL-EXHAUST | 2 | |
| 1W0481 | 10 RING-EXHAUST SEAL | 2 | |
| 1W5651 | 11 TUBE AS-EXHAUST | 1 | |
| 8N0879 | 12 CLAMP | 4 | |
| 0S1608 | 13 BOLT (3/8-16X3.75-IN) | 2 | |
| 0S1588 | 14 BOLT (3/8-16X1.25-IN) | 6 | |
| 2W9624 | 15 SUPPORT-TURBOCHARGER | 1 | |
| 8N2258 | 16 SHIELD AS-BOTTOM | 1 | |
| 1W5654 | 17 TUBE AS-EXHAUST | 1 | |
| 1W5653 | 18 TUBE AS-EXHAUST | 1 | |
| 4L8337 | 19 SEAL-O-RING | 2 | |
| 5P9959 | 20 BOLT (5/16-18X0.5-IN) | 2 | |
| 9M1974 | 21 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 1W6186 | 22 SHIELD AS | 1 | |
| 1W6308 | 23 PLATE | 1 | |
| 6L3670 | 24 BOLT (3/8-16X7.75-IN) | 2 | |
| 5M2894 | 25 WASHER-HARD (10.2X18.5X2.5-MM THK) | 14 | |
| 0T0065 | 26 BOLT (3/8-16X3.5-IN) | 3 | |
| 0679846 | 27 SPACER | 3 | |
| 3B1915 | 28 BOLT (3/8-16X1.375-IN) | 5 | |
| 1W5382 | 29 GASKET | 1 | |
| 8S7941 | 30 PIPE | 2 | |
| 5P2755 | 31 BOLT-HIGH TEMPERATURE (3/8-16X2.75-IN) | 4 | |
| 1C2251 | 32 BOLT (3/8-16X1.87-IN) | 2 | |
| 8N2574 | 33 BRACKET | 1 | |
| 0S1594 | 34 BOLT (3/8-16X1-IN) | 2 | |
| 5B7890 | 35 PLUG-PIPE | 2 | |
| 5M6213 | 36 PLUG-PIPE (1/4-18-THD) | 1 | |
| 1W5108 | 37 GASKET | 1 | |
| 1D4717 | 38 NUT (3/8-16-THD) | 1 | |
| 6F7012 | 39 STUD-TAPERLOCK (3/8-16X1.57-IN) | 1 |
