System And Components
6G-4670 CONTROL GP-GOVERNORS/N 90Z1-112; 91Z1-203
Group No: 6G-4670
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6G5176 | 1 TUBE AS | 1 | |
| 5K9246 | 2 CONNECTOR | 4 | |
| 5K9235 | 3 ELBOW-FLARED | 2 | |
| 6G4700 | 4 VALVE GP-AIR CONTROL | 1 | |
| 0315085 | 5 BOLT-LOCKING (1/4-20X1-IN) | 3 | |
| 5P0537 | WASHER-HARD (7.2X14.5X2-MM THK) | 3 | |
| 1B0676 | 6 PIN | 5 | |
| 3B4615 | PIN-COTTER | 5 | |
| 4J8922 | 7 ROD END (3/8-24-THD) | 4 | |
| 5B9079 | 8 NUT-JAM (3/8-24-THD) | 4 | |
| 2K6901 | 9 ROD | 1 | |
| 3K9042 | 10 RING-RETAINING | 2 | |
| 7S9203 | WASHER | 2 | |
| 6G4661 | 11 HOUSING AS | 2 | |
| 6D3787 | BEARING-ROLLER | 1 | |
| 5P7661 | BEARING AS-NEEDLE | 1 | |
| 9S8006 | 12 PLUG (7/8-14-THD) | 4 | |
| 6G5174 | 13 TUBE AS | 1 | |
| 1B4669 | 14 COLLAR-SET | 2 | |
| 4B3573 | SETSCREW-SQUARE HEAD (3/8-16X0.625-IN) | 2 | |
| 1B2578 | NUT (3/8-16-THD) | 2 | |
| 6G4449 | 15 SHAFT | 1 | |
| 2J3118 | 16 BOLT-LOCKING (3/8-16X1.25-IN) | 6 | |
| 5M2894 | 17 WASHER-HARD (10.2X18.5X2.5-MM THK) | 14 | |
| 8D5253 | 18 BRACKET AS | 1 | |
| 4D2619 | BEARING | 1 | |
| 4J2684 | 19 LEVER | 1 | |
| 1B8704 | 20 KEY-WOODRUFF | 3 | |
| 0308537 | 21 BOLT-LOCKING (3/8-16X1.5-IN) | 3 | |
| 1D4717 | NUT (3/8-16-THD) | 3 | |
| 6G5177 | 22 TUBE AS | 1 | |
| 6G4438 | 23 PEDAL | 2 | |
| 1B8706 | 24 KEY-WOODRUFF | 4 | |
| 6G8909 | 25 SHAFT | 2 | |
| 8J4916 | 26 BOSS (3/8-16-THD) | 2 | |
| 4J2701 | 27 ROD END | 1 | |
| 6D4397 | 28 ROTOCHAMBER GP | 1 | |
| 6G4443 | 29 BRACKET | 1 | |
| 6V6582 | BEARING | 1 | |
| 4D8919 | 30 LEVER | 1 | |
| 5D1849 | 31 LEVER | 1 | |
| 9H4361 | 32 ROD | 1 | |
| 6G4448 | 33 LEVER | 1 | |
| 0308535 | 34 BOLT-LOCKING (3/8-16X0.875-IN) | 10 | |
| 4B3388 | 35 BOLT (5/16-18X1.125-IN) | 2 | |
| 5D0353 | 36 BOLT-LOCKING (3/8-16X1-IN) | 2 | |
| 5B9079 | 37 NUT-JAM (3/8-24-THD) | 5 | |
| 5J6131 | 38 ROD-CONTROL | 1 | |
| 4D4064 | 39 ROD END (3/8-24-THD) | 3 | |
| 5P9938 | 40 BOLT-HEAD LOCKING (3/8-16X1.375-IN) | 3 | |
| 1D4717 | 41 NUT (3/8-16-THD) | 5 | |
| 5M2894 | 42 WASHER-HARD (10.2X18.5X2.5-MM THK) | 9 | |
| 4K5973 | 43 LEVER | 1 | |
| 1B8704 | 44 KEY-WOODRUFF | 2 | |
| 6G4451 | 45 SHAFT | 1 | |
| 6D0475 | 46 LINK AS-SPRING | 1 | |
| 5H4215 | 47 ROD | 1 | |
| 6G4443 | 48 BRACKET | 1 | |
| 6V6582 | 49 BEARING | 2 | |
| 5D0353 | 50 BOLT-LOCKING (3/8-16X1-IN) | 2 | |
| 0S1588 | 51 BOLT (3/8-16X1.25-IN) | 2 | |
| 5T4064 | 52 BRACKET | 1 | |
| 0308537 | 53 BOLT-LOCKING (3/8-16X1.5-IN) | 2 | |
| 5J5315 | 54 ROD END | 1 | |
| 5H8633 | LOCKNUT (3/8-24-THD) | 1 | |
| 4D2615 | 55 LEVER | 1 | |
| 7F3425 | 56 BOLT (3/8-16X5.75-IN) | 1 | |
| 6G4444 | 57 BRACKET AS | 1 | |
| 0T0065 | 58 BOLT (3/8-16X3.5-IN) | 1 | |
| 1S5927 | 59 LEVER-GOVERNOR CONTROL | 1 | |
| 2A5546 | 60 BOLT (1/4-20X1.375-IN) | 1 | |
| 1B4330 | NUT (1/4-20-THD) | 1 | |
| 4H6147 | 61 CONNECTOR | 4 | |
| 3D6931 | 62 HOSE AS | 1 | |
| 9M8662 | 63 COUPLING | 3 | |
| 5K9246 | 64 CONNECTOR | 2 | |
| 6G8439 | 65 TUBE AS | 1 | |
| 7D5998 | 66 HOSE AS | 2 | |
| 5H4778 | 67 ELBOW | 6 | |
| 4S7606 | 68 ELBOW | 3 | |
| 2G3787 | 69 BUTTON | 1 | |
| 5D1319 | PIN-SPRING | 1 | |
| 6G8920 | 70 VALVE GP-AIR CONTROL | 1 | |
| 5M6214 | PLUG (1/8-27 PTF) | 1 | |
| 3B6493 | 71 ELBOW | 1 | |
| 3B7263 | NIPPLE-PIPE | 1 | |
| 4D2560 | CONNECTOR-PIPE | 1 | |
| 4S7565 | 72 HOSE AS | 1 | |
| 4D7969 | 73 HOSE AS | 1 | |
| 4S7572 | 74 HOSE AS | 1 | |
| 0308535 | 75 BOLT-LOCKING (3/8-16X0.875-IN) | 1 | |
| 5M2894 | WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 | |
| 6D3781 | 76 VALVE GP-CHECK | 1 | |
| 5D7464 | 77 HOSE AS | 1 | |
| 4D7928 | 78 HOSE AS | 1 | |
| 2D0193 | 79 CONNECTOR-PIPE | 1 | |
| 2D7325 | 80 TEE-PIPE | 1 |
