System And Components
6G-4670 CONTROL GP-GOVERNORS/N 90Z138-UP; 91Z225-UP
Group No: 6G-4670
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6G5176 | 1 TUBE AS | 1 | |
| 5K9246 | 2 CONNECTOR | 6 | |
| 5K9235 | 3 ELBOW-FLARED | 2 | |
| 6G4700 | 4 VALVE GP-AIR CONTROL | 1 | |
| 8T8908 | 5 BOLT (1/4-20X1-IN) | 3 | |
| 8T4205 | WASHER-HARD (7.2X14.5X2-MM THK) | 3 | |
| 1B0676 | 6 PIN | 5 | |
| 4J8922 | 7 ROD END (3/8-24-THD) | 4 | |
| 5B9079 | 8 NUT-JAM (3/8-24-THD) | 4 | |
| 2K6901 | 9 ROD | 1 | |
| 3K9042 | 10 RING-RETAINING | 2 | |
| 7S9203 | WASHER | 2 | |
| 6G4661 | 11 HOUSING AS | 2 | |
| 6D3787 | BEARING-ROLLER | 1 | |
| 5P7661 | BEARING AS-NEEDLE | 1 | |
| 9S8006 | 12 PLUG (7/8-14-THD) | 4 | |
| 6G5174 | 13 TUBE AS | 1 | |
| 1B4669 | 14 COLLAR-SET | 2 | |
| 4B3573 | SETSCREW-SQUARE HEAD (3/8-16X0.625-IN) | 2 | |
| 5T9623 | 15 SHAFT | 1 | |
| 5S7382 | 16 BOLT (3/8-16X1.375-IN) | 2 | |
| 8T4896 | 17 WASHER-HARD (10.2X18.5X2.5-MM THK) | 10 | |
| 5T8919 | 18 BEARING | 2 | |
| 4J2684 | 19 LEVER | 1 | |
| 1B8704 | 20 KEY-WOODRUFF | 3 | |
| 4L9337 | 21 BOLT (3/8-16X1.5-IN) | 3 | |
| 6V8801 | NUT (3/8-16-THD) | 3 | |
| 6G5177 | 22 TUBE AS | 1 | |
| 6G4438 | 23 PEDAL | 2 | |
| 1B8706 | 24 KEY-WOODRUFF | 4 | |
| 6G8909 | 25 SHAFT | 2 | |
| 8J4916 | 26 BOSS (3/8-16-THD) | 2 | |
| 4J2701 | 27 ROD END | 1 | |
| 6D4397 | 28 ROTOCHAMBER GP | 1 | |
| 8T4224 | 29 WASHER-HARD (8.8X16X2-MM THK) | 6 | |
| 4D8919 | 30 LEVER | 1 | |
| 5D1849 | 31 LEVER | 1 | |
| 9H4361 | 32 ROD | 1 | |
| 6G4448 | 33 LEVER | 1 | |
| 5S7379 | 34 BOLT (3/8-16X0.875-IN) | 10 | |
| 6V5782 | 35 BOLT (5/16-18X1.125-IN) | 2 | |
| 5K0906 | 36 BOLT (5/16-18X0.625-IN) | 2 | |
| 7X0860 | 37 BOLT (3/8-16X1.5-IN) | 2 | |
| 1B2578 | 38 NUT (3/8-16-THD) | 2 | |
| 6G5173 | 39 TUBE AS | 1 | |
| 8T9043 | 40 BOLT (5/16-18X0.875-IN) | 2 | |
| 0314155 | LOCKNUT (5/16-18-THD) | 2 | |
| 5P0372 | 41 LOCK PIN | 2 | |
| 7V0446 | 42 CLIP | 3 | |
| 5B9079 | 43 NUT-JAM (3/8-24-THD) | 5 | |
| 5J6131 | 44 ROD-CONTROL | 1 | |
| 4D4064 | 45 ROD END (3/8-24-THD) | 3 | |
| 5S7382 | 46 BOLT (3/8-16X1.375-IN) | 3 | |
| 6V8801 | 47 NUT (3/8-16-THD) | 5 | |
| 8T4896 | 48 WASHER-HARD (10.2X18.5X2.5-MM THK) | 7 | |
| 4K5973 | 49 LEVER | 1 | |
| 1B8704 | 50 KEY-WOODRUFF | 2 | |
| 5T8843 | 51 SHAFT | 1 | |
| 6D0475 | 52 LINK AS-SPRING | 1 | |
| 5H4215 | 53 ROD | 1 | |
| 0314155 | 54 LOCKNUT (5/16-18-THD) | 4 | |
| 8T4224 | WASHER-HARD (8.8X16X2-MM THK) | 8 | |
| 5T8919 | 55 BEARING | 2 | |
| 4L6454 | 56 BOLT (3/8-16X1-IN) | 2 | |
| 8T9043 | 57 BOLT (5/16-18X0.875-IN) | 4 | |
| 5T8836 | 58 PLATE AS | 1 | |
| 4L9337 | 59 BOLT (3/8-16X1.5-IN) | 5 | |
| 5J5315 | 60 ROD END | 1 | |
| 2F8616 | NUT-SELF LOCKING (3/8-24-THD) | 1 | |
| 4J2684 | 61 LEVER | 1 | |
| 7X0297 | 62 BOLT (3/8-16X5.75-IN) | 1 | |
| 5T8838 | 63 PLATE AS | 1 | |
| 8T5390 | 64 BOLT (3/8-16X3.5-IN) | 1 | |
| 1102908 | 65 LEVER-GOVERNOR | 1 | |
| 8C3121 | 66 BOLT (5/16-18X1.5-IN) | 1 | |
| 6V8189 | NUT (5/16-18-THD) | 1 | |
| 4H6147 | 67 CONNECTOR | 5 | |
| 3D6931 | 68 HOSE AS | 1 | |
| 9M8662 | 69 COUPLING | 3 | |
| 5K9246 | 70 CONNECTOR | 2 | |
| 6G8439 | 71 TUBE AS | 1 | |
| 7D5998 | 72 HOSE AS | 1 | |
| 5H4778 | 73 ELBOW | 6 | |
| 4S7606 | 74 ELBOW | 2 | |
| 2G3787 | 75 BUTTON | 1 | |
| 5D1319 | PIN-SPRING | 1 | |
| 6G8920 | 76 VALVE GP-AIR CONTROL | 1 | |
| 5M6214 | PLUG (1/8-27 PTF) | 1 | |
| 3B6493 | 77 ELBOW | 1 | |
| 3B7285 | NIPPLE-PIPE | 1 | |
| 4D2560 | CONNECTOR-PIPE | 1 | |
| 4S7565 | 78 HOSE AS | 1 | |
| 4D7969 | 79 HOSE AS | 1 | |
| 4S7572 | 80 HOSE AS | 1 | |
| 5S7379 | 81 BOLT (3/8-16X0.875-IN) | 1 | |
| 8T4896 | WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 | |
| 6D3781 | 82 VALVE GP-CHECK | 1 | |
| 5D7464 | 83 HOSE AS | 1 | |
| 4D7928 | 84 HOSE AS | 1 | |
| 2D0193 | 85 CONNECTOR-PIPE | 1 | |
| 2D7325 | 86 TEE-PIPE | 2 | |
| 4D7928 | 87 HOSE AS | 1 |
