Assembly
100%

8N-2404 AFTERCOOLER GP-WATERS/N 73W5102-UP

Group No: 8N-2404
Part NumberPart NameQty
1W53811 COVER1
0S15712 BOLT (3/8-16X1.75-IN)10
5M28943 WASHER-HARD (10.2X18.5X2.5-MM THK)32
7W64924 PLUG-PIPE (1/2-14-THD)2
2W65965 CORE AS-AFTERCOOLER1
8N22996 ADAPTER2
10900737 SEAL-O-RING4
2W66878 ADAPTER2
0S15909 BOLT (3/8-16X2-IN)4
109007910 SEAL-O-RING2
8N270511 HOUSING1
4N256412 GASKET1
0T057313 BOLT (3/8-16X2.75-IN)14
0S161714 BOLT (5/16-18X0.75-IN)1
9M197415 WASHER-HARD (8.8X16X2-MM THK)8
4N862816 GASKET1
1B718217 BOLT (5/16-18X1.25-IN)7
0S157118 BOLT (3/8-16X1.75-IN)4
0S159019 BOLT (3/8-16X2-IN)1
5M289420 WASHER-HARD (10.2X18.5X2.5-MM THK)4
0L207021 BOLT (3/8-16X2.25-IN)1
5B2638BOLT (3/8-16X5.25-IN)1
0L207022 BOLT (3/8-16X2.25-IN)2
