7N-1328 SHIELD GP-MANIFOLDS/N 89Z1-94

Group No: 7N-1328
Part NumberPart NameQty
5M28941 WASHER-HARD (10.2X18.5X2.5-MM THK)10
9M19742 WASHER-HARD (8.8X16X2-MM THK)55
8N23683 SHIELD AS1
2H37554 BOLT (5/16-18X0.43-IN)23
1B53545 NUT-FULL (5/16-18-THD)32
1N33006 SHIELD AS4
8N15947 SHIELD AS2
6V27128 STUD16
1W61839 SHIELD AS-MANIFOLD1
6V5044NUT-WELD (5/16-18-THD)10
8N161610 SHIELD AS2
8N161911 SHIELD AS2
0S159412 BOLT (3/8-16X1-IN)9
1W339713 PLATE2
0S158714 BOLT (1/2-13X1.75-IN)2
5P8245WASHER-HARD (13.5X25.5X3-MM THK)2
8N795315 PLATE1
1W618416 SHIELD AS1
6V5044NUT-WELD (5/16-18-THD)10
1N473417 CLAMP2
0S158818 BOLT (3/8-16X1.25-IN)1
5P995919 BOLT (5/16-18X0.5-IN)6
4B427720 WASHER (8.8X17.5X1.6-MM THK)4
8N795421 PLATE2
8N795322 PLATE1
9M197423 WASHER-HARD (8.8X16X2-MM THK)2
0S158724 BOLT (1/2-13X1.75-IN)4
5P8245WASHER-HARD (13.5X25.5X3-MM THK)4
1W618525 SHIELD AS1
6V5044NUT-WELD (5/16-18-THD)2
0L114326 BOLT (3/8-16X2.5-IN)1
5M2894WASHER-HARD (10.2X18.5X2.5-MM THK)2
1D4717NUT (3/8-16-THD)1
2P091127 ANGLE1
0S157128 BOLT (3/8-16X1.75-IN)2
