System And Components
8N-3310 BELT TENSIONER GPS/N 86Z1-125; 87Z1-UP
Group No: 8N-3310
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8N3328 | 1 ARM AS-TIGHTENER | 1 | |
| 4S5367 | BUSHING AS (MOUNT) | 1 | |
| 4N0955 | DOWEL | 1 | |
| 8N3301 | 2 SHAFT-TIGHTENER | 1 | |
| 2M2742 | 3 PLATE-RETAINER | 1 | |
| 0L1351 | 4 BOLT (3/8-16X0.875-IN) | 1 | |
| 5M2894 | 5 WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 | |
| 8N3304 | 6 PULLEY-TIGHTENER | 1 | |
| 5M9735 | 7 SEAL-LIP TYPE | 1 | |
| 6B1124 | 8 BALL BEARING | 2 | |
| 8N3300 | 9 SPACER | 1 | |
| 8B2327 | 10 RING-RETAINING | 1 | |
| 2S6160 | 11 WASHER-HARD (10.2X32X5-MM THK) | 1 | |
| 0S0509 | 12 BOLT (3/8-16X0.75-IN) | 1 | |
| 2S6150 | 13 COVER-PULLEY | 1 | |
| 2S6151 | 14 GASKET | 1 | |
| 0S1618 | 15 BOLT (5/16-18X1-IN) | 4 | |
| 2S6689 | 16 RETAINER-SPRING | 1 | |
| 1D4719 | 17 NUT-FULL (1/2-13-THD) | 1 | |
| 2M0849 | 18 WASHER-HARD (13.5X25.5X5-MM THK) | 1 | |
| 7N5959 | 19 SPRING | 1 | |
| 0S0175 | 20 PIN-CLEVIS | 2 | |
| 3B4617 | 21 PIN-COTTER | 2 | |
| 3B8489 | 22 FITTING-GREASE (1/8-27 PTF) | 1 |
