Assembly
100%

1W-5082 CYLINDER BLOCK GPS/N 48W19977-UP

Group No: 1W-5082
Part NumberPart NameQty
7W49901 JET AS-PISTON COOLING8
4N16502 DOWEL4
8T67633 PLUG-PIPE (1/4-18-THD)4
1W50814 CYLINDER BLOCK AS1
8T67575 PLUG-PIPE7
6N91336 GASKET-PLATE2
6I46137 PLATE-SPACER2
4N06938 PLUG-TAPERLOCK (1-1/2-12-THD)(38.10MM OD)3
7C9614PLUG-TAPERLOCK (1-5/8-12-THD)(41.28MM OD)3
4N06839 DOWEL4
7E647910 BOLT-SPECIAL (OIL JET)8
3B064511 PLUG-CUP (32.08-MM OD)1
6L442812 STUD-TAPERLOCK (3/8-16X4.01-IN)3
2M978013 SEAL-O-RING2
7W653414 PLUG-PIPE2
8M828315 SEAL-O-RING2
3S660516 PLUG-CUP2
9S419017 PLUG-O-RING (7/8-14-THD)2
8T676418 PLUG-PIPE (1/8-27-THD)1
7C740719 STUD (3/8-16X1.44-IN)1
7W653420 PLUG-PIPE1
9S419021 PLUG-O-RING (7/8-14-THD)2
2M9780SEAL-O-RING2
7W653422 PLUG-PIPE1
7W653423 PLUG-PIPE1
7W653424 PLUG-PIPE1
4W6061SLEEVE
4W4588SLEEVE-LIFTER BORE
9Y3368INSERT-LINER SEAT (0.822-MM THK)
6I4361INSERT-LINER SEAT (0.772-MM THK)
6I4362INSERT-LINER SEAT (0.872-MM THK)
2W3815INSERT-LINER SEAT (1.605-MM THK)
6I4361INSERT-LINER SEAT (0.772-MM THK)
6I4362INSERT-LINER SEAT (0.872-MM THK)
5N0093INSERT-LINER SEAT (2.71-MM THK)
6I4365INSERT-LINER SEAT (2.66-MM THK)
6I4366INSERT-LINER SEAT (2.76-MM THK)
1010523INSERT-LINER SEAT (5.21-MM THK)
