4N-1816 CYLINDER HEAD GPS/N 48W15036-17630

Group No: 4N-1816
Part NumberPart NameQty
1W78851 ADAPTER AS-FUEL VALVE8
2S22512 SEAL-O-RING8
4N72533 GASKET-CHAMBER8
5M62144 PLUG (1/8-27 PTF)2
7N08575 CYLINDER HEAD GP2
0L13526 BOLT (3/8-16X3.25-IN)11
3J53907 PLUG (3/8-18-THD)2
3J53898 PLUG (EXTERNAL)2
1B51749 PLUG-PIPE2
4S613710 STUD-TAPERLOCK (3/8-16X3.1-IN)16
4N182011 GASKET-CYLINDER HEAD2
2H375012 BOLT (3/4-16X7.5-IN)28
5H1504WASHER-HARD (20X33.5X5-MM THK)28
4N226913 SEAL32
5P006314 PLUG-CUP4
4N093215 PLUG-CUP (57.53-MM OD)2
1A518316 BOLT (3/8-16X4.75-IN)2
5M289417 WASHER-HARD (10.2X18.5X2.5-MM THK)5
5B263818 BOLT (3/8-16X5.25-IN)2
6N673119 SUPPORT-HOUSING (LH)1
6N673220 SUPPORT-HOUSING (RH)1
2B085821 PLUG-PIPE2
8S919122 BOLT (3/8-16X4-IN)3
0S159123 BOLT (3/8-16X1.5-IN)2
1W520724 BRACKET-FUEL PUMP1
9N258325 BRACKET-FUEL PUMP1
