System And Components
4W-4486 DRIVE GP-FANS/N 86Z103-UP
Group No: 4W-4486
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T8919 | 1 BOLT (1/2-13X1.75-IN) | 2 | |
| 8T4223 | 2 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 8T9391 | 3 BOLT (1/2-13X3.75-IN) | 2 | |
| 4W4184 | 4 BRACKET AS-FAN | 1 | |
| 8N8980 | 5 SHAFT-FAN | 1 | |
| 4N0955 | 6 DOWEL | 1 | |
| 1S9209 | 7 SHAFT-TIGHTENER | 1 | |
| 8N8979 | 8 SPACER (42X54X90-MM THK) | 1 | |
| 4W4183 | 9 HUB | 1 | |
| 6H3957 | 10 BALL BEARING | 2 | |
| 6H3956 | 11 PIN | 1 | |
| 4W4079 | 12 ADAPTER-FAN | 1 | |
| 5N4751 | 13 V-BELT SET (INCLUDES 3-BELTS)(3 BELTS) | 1 | |
| 8T9378 | 14 BOLT (3/8-16X4-IN) | 6 | |
| 8N8978 | 15 SPACER (40X53.98X20-MM THK) | 1 | |
| 8B8255 | 16 SEAL-LIP TYPE | 1 | |
| 8L6557 | 17 CONNECTOR | 2 | |
| 7N1275 | 18 PULLEY-FAN DRIVE | 1 | |
| 7X7890 | 19 BOLT (5/8-11X9.5-IN) | 1 | |
| 1W4564 | 20 WASHER-RETAINING (17X54X25-MM THK) | 1 | |
| 5H8624 | 21 SEAL-O-RING | 1 | |
| 3B8485 | 22 ELBOW | 1 | |
| 6N4111 | 23 BRACKET AS | 1 | |
| 9B7237 | 24 BOLT (3/8-16X1.25-IN) | 2 | |
| 8T4896 | WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 2B2404 | 25 CLIP | 1 | |
| 4W4492 | 26 TUBE AS | 1 |
