System And Components
4N-8160 LINES GP-ENGINE OILS/N 48W15036-UP
Group No: 4N-8160
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1090076 | 1 SEAL-O-RING | 3 | |
| 0S1594 | 2 BOLT (3/8-16X1-IN) | 10 | |
| 1090078 | 3 SEAL-O-RING | 2 | |
| 1W1116 | 4 BODY-BYPASS | 1 | |
| 1142687 | 5 SEAL-O-RING | 2 | |
| 0T0065 | 6 BOLT (3/8-16X3.5-IN) | 1 | |
| 0S1608 | 7 BOLT (3/8-16X3.75-IN) | 1 | |
| 4N8770 | 8 ELBOW-COOLER OUTLET | 1 | |
| 4N8410 | 9 TUBE-COOLER BYPASS | 1 | |
| 3B1915 | 10 BOLT (3/8-16X1.375-IN) | 1 | |
| 5M2894 | 11 WASHER-HARD (10.2X18.5X2.5-MM THK) | 7 | |
| 0L2070 | 12 BOLT (3/8-16X2.25-IN) | 1 | |
| 1P1367 | 13 PLUNGER (RELIEF VALVE) | 2 | |
| 9F6304 | 14 SPRING | 2 | |
| 4N0861 | 15 COVER | 1 | |
| 4N0865 | GASKET | 1 | |
| 0S1571 | 16 BOLT (3/8-16X1.75-IN) | 1 | |
| 0S1591 | 17 BOLT (3/8-16X1.5-IN) | 1 | |
| 4N1413 | 18 TUBE AS | 1 | |
| 1090078 | 19 SEAL-O-RING | 1 | |
| 1090072 | 20 SEAL-O-RING | 1 | |
| 0L1351 | 21 BOLT (3/8-16X0.875-IN) | 1 | |
| 8M9024 | WASHER-HARD (10.2X22.5X5-MM THK) | 1 | |
| 9N5917 | 22 TUBE AS-PUMP SUCTION | 1 | |
| 0S1588 | 23 BOLT (3/8-16X1.25-IN) | 2 | |
| 8N2104 | 24 BELL AS-SUCTION | 1 | |
| 9F2978 | NUT-WELD (3/8-16-THD) | 2 | |
| 4N0913 | 25 SCREEN-STRAINER | 1 | |
| 4N0914 | 26 CLIP | 1 | |
| 1232894 | 27 SUPPORT-SUCTION LINE | 1 |
