System And Components
8N-4425 LINES GP-TURBOCHARGER OILS/N 48W15036-17791
Group No: 8N-4425
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1W8040 | 1 TUBE AS-OIL | 1 | |
| 0S1608 | 2 BOLT (3/8-16X3.75-IN) | 2 | |
| 4H9541 | 3 GASKET | 1 | |
| 7N7559 | 4 GASKET | 1 | |
| 1N4734 | 5 CLAMP | 2 | |
| 0L1143 | 6 BOLT (3/8-16X2.5-IN) | 1 | |
| 5M2894 | 7 WASHER-HARD (10.2X18.5X2.5-MM THK) | 6 | |
| 1D4717 | 8 NUT (3/8-16-THD) | 4 | |
| 0S1591 | 9 BOLT (3/8-16X1.5-IN) | 2 | |
| 1W7999 | 10 BRACKET | 1 | |
| 1W5378 | 11 ELBOW-DRAIN | 1 | |
| 9L6924 | 12 GASKET | 1 | |
| 8N3138 | 13 ELBOW-DRAIN | 1 | |
| 6F7012 | 14 STUD-TAPERLOCK (3/8-16X1.57-IN) | 2 | |
| 6M7476 | 15 ELBOW | 1 | |
| 6K4938 | 16 CLIP | 1 | |
| 0S1594 | 17 BOLT (3/8-16X1-IN) | 1 | |
| 6K4939 | 18 CLIP | 1 | |
| 2M9780 | 19 SEAL-O-RING | 1 | |
| 1W8038 | 20 TUBE AS | 1 | |
| 9M4849 | 21 SEAL-O-RING | 2 | |
| 8N7966 | 22 TUBE | 1 | |
| 0S1571 | 23 BOLT (3/8-16X1.75-IN) | 1 | |
| 0618248 | 24 UNION-FLARED | 1 | |
| 0L1351 | 25 BOLT (3/8-16X0.875-IN) | 1 | |
| 9M7228 | 26 BRACKET | 1 |
