System And Components
Assembly
100%

137-8419 LINES GP-AIRS/N 48W19977-40737

Group No: 137-8419
Part NumberPart NameQty
0L13521 BOLT (3/8-16X3.25-IN)6
0L20702 BOLT (3/8-16X2.25-IN)2
0S15713 BOLT (3/8-16X1.75-IN)3
0S15884 BOLT (3/8-16X1.25-IN)3
0S15945 BOLT (3/8-16X1-IN)2
1A20296 BOLT (3/8-16X1.125-IN)4
1C22517 BOLT (3/8-16X1.87-IN)2
1W04818 RING-EXHAUST SEAL2
9Y21519 TUBE AS-EXHAUST1
3E742810 PLUG-PIPE (1/4-18-THD)2
4W431411 SUPPORT-TURBOCHARGER1
5M289412 WASHER-HARD (10.2X18.5X2.5-MM THK)19
5P275513 BOLT-HIGH TEMPERATURE (3/8-16X2.75-IN)4
9Y215014 TUBE AS-EXHAUST1
7E320515 MANIFOLD-INLET1
8N087816 CLAMP2
8N087917 CLAMP4
8N225818 SHIELD AS-BOTTOM1
6V5044NUT-WELD (5/16-18-THD)7
9M4136SPACER (0.438X0.75X0.5-IN THK)5
8N257419 BRACKET1
8N482320 SUPPORT AS1
129941621 GASKET1
9S875222 NUT-FULL (3/8-16-THD)5
9Y214823 TUBE AS-EXHAUST1
9Y214924 TUBE AS-EXHAUST1
106940825 SEAL-EXHAUST2
